100/600 Series Incandescent Neon
&
LED Panel Mount Indicators
- RoHS Compliant
Special Features
• Built-in T1 3/4 incandescent, T2 neon bulbs, or T1 3/4 LEDs
• Standard termination—2˝ stranded insulated leads or bi-pins
(other lead lengths available upon request)
• Rapid assembly with non-corrosive tinnerman speed nut (furnished)
• Sealed against moisture and dust—water resistant
• Optically engineered lens provides full 180° visibility
• Explosion proof—meets requirements of MIL-E-5400
• Simplified one piece plastic lens and body
Panel Mount Incandescent, Neon, and
LED Indicators
NEON (Use Bulb Type Nos.)
MAX. BREAKDOWN
INTERNAL
BULB
VOLTAGE
CIRCUIT
LIFE
RESISTOR
TYPE
VOLTAGE WATTS HOURS ATTACHED
AC
DC
High Brightness—Dark Starting
1204(C2A)
45
135
120
1/4
25,000
None*
1211(RC2X)
45
135
120
1/4
25,000
47K
Standard Brightness—Not recommended with Translucent Lens
1202(A9A)
65
90
120
1/15 25,000
None*
1201(RA9X)
65
90
240
1/15 25,000
100K
Economy version available—(unit sealed and no insulation on leads).
To order place “N” before bulb type.
Green neon lamps are also available.
*Note:
Neon assemblies without resistor attached require a current
limiting device in the circuit.
LEDs (See pages 24-27, 29-30)
Electrical and Optical Characteristics
INCANDESCENT (Use Bulb Type Nos.)
BULB
TYPE
H519
M521
M522
H524
M525
M526
M527
H529
H533
H538
M540
M542
HM550
HM553
M555
M801
M802
OPERATING
VOLTAGE
2.5
6.0
3.0
6.3
6.3
6.3
6.0
6.3
14.0
14.0
12.0
18.0
28.0
28.0
28.0
10.0
10.0
CURRENT
AMPERIES
.200
.200
.015
.200
.040
.075
.040
.200
.080
.080
.040
.040
.040
.040
.040
.014
.040
HOURS
LIFE
500
1,000
10,000
3,000
50,000
500
10,000
50,000
2,500
50,000
10,000
10,000
4,000
25,000
50,000
50,000
30,000
Specifications
• Front mounts in 5/16˝ (7.94) hole with
tinnerman nut or 1/2˝ hole with nickel
steel bezel
• Center-to-Center spacing:
1/2˝ for 5/16˝ mounting and
3/4˝ for 1/2˝ mounting
• Materials: High impact butyrate plastic
body and lens-22 AWG PVC 1/32˝
insulated leads, 105°C, 600 Volt (7/30)
or bi-pins—Brass 1/2 hard, gold plated
• Hot stamping legends available;
four 6 pt. (5/64˝); three 8 pt. (3/32˝); or
three 10 pt. (1/8˝) characters in black or
white (not available on 100 Series)
• Unassembled, friction-fit 8˝ lead
economy series available
Package Dimensions
1.109 (28.2)
.92 (23.4)
.020
(.5)
.185
(4.7)
.375
(9.5)
.020
(.5)
.185
(4.7)
1.109 (28.2)
.92 (23.4)
.375
(9.5)
.185
(4.7)
1.109 (28.2)
.92 (23.4)
.375
(9.5)
1.109 (28.2)
.92 (23.4)
.185
(4.7)
.047
(1.2)
.020
(.5)
.340
(8.6)
.020
(.5)
.339
(8.6)
.336
(8.5)
.307
(7.8)
.039
(.99)
.304
(7.7)
.160
(4.1)
.039
(.99)
.339
(8.6)
.307
(7.8)
.039
(.99)
.160
(4.1)
.307
(7.8)
.160
(4.1)
.039
(.99)
.160
(4.1)
Model 150
All Dimensions are in inches (mm)
Model 250
Model 550
Model 650
Lens Color Code
1.
2.
3.
4.
5.
Transparent Amber
Transparent Red
Transparent Blue*
Transparent Green*
Transparent Clear
6.
7.
8.
9.
10.
Translucent Yellow
+
Translucent Red
+
Translucent Blue*
+
Translucent Green*
+
Translucent White
+
How To Order
Termination Lens Color
x x x — x — x x x x
Series No.
2" Wire Leads = 0
Bi-pins = 5
8" Long Leads Economy = 9
Mounting 5/16" Hole = 0
1/2" Hole Using Bezel = 2
See
Lens Color
Code
Bulb Type
(See bulb charts
or LED Part #)
Note:
* Blue and green lenses not recommended for use with
neon bulbs.
+
Translucent lenses not recommended for use with
neon bulbs and LEDs.
®
WILBRECHT
ELECTRONICS, INC.
LEDCO
DIVISION
18
1400 Energy Park Drive, Suite 18 • St. Paul, MN 55108-5248 • (651) 659-0919 • Toll free (888) 323-8751 • FAX (651) 659-9204 • www.wilbrecht.com
