450-0016-01-06-00 datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> terminals> 450-0016-01-06-00

Preview

450-0016-01-06-00: DescriptionWire Terminal; CategoryThe connector terminals; File Size183KB，1 Pages; ManufacturerCambion Electronics Ltd.; Websitehttp://www.cambion.com/; Environmental Compliance

Download Datasheet Parametric View All

450-0016-01-06-00 Overview

Wire Terminal

450-0016-01-06-00 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Cambion Electronics Ltd.
Reach Compliance Code	compliant
ECCN code	EAR99
terminal gender	FEMALE
Terminal and terminal strip types	WIRE TERMINAL
Wire gauge	16 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

SINGLE POLE SOCKETS - PATCHCORD CRIMP

Dimensions in inches (mm)

How to order code

450 - XXXX - 01 - XX - XX

Basic Part No.

Insulator

Colour

Socket Finish

Material Code Table

Component

Body

Spring

Insulation

Fig.

1

450-1807 -01

2

450-0016 -01

Basic Part

No.

450-3367 -01

Material

Brass

RoHS

✓

A

.224 (5.69)

.420 (10.67)

.234 (5.94)

Finish Code Table

Dash No.

Body Finish

-03

-04

-06

B

.306 (7.77)

.296 (7.52)

C

.185 (4.70)

.375 (9.53)

.190 (4.83)

Gold over Nickel

Electro-Tin

D

.105 (2.67)

.170 (4.32)

.141 (3.58)

Spring Finish

Gold over Nickel

Electro-Tin

Gold over Nickel

D1

.091 (2.29)

.143 (3.63)

.119 (3.02)

E

RoHS

✓

Insulation Colour Code Table

Dash No.

Colour

-00

-10

F

.060 (1.52)

.076 (1.93)

G

None

Black

H

Beryllium Copper

(Heat Treated)

Polyolefin Plastic

P

.040 (1.02)

.080 (2.03)

.061 (1.55)

.031 (0.79)

.046 (1.17)

.029 (0.74) .282 (7.16)

.039 (0.99) .267 (6.78)

Also available with black polyolefin sleeve as 450-3378-01-XX-10

Also available with black polyolefin sleeve as 450-3413-01-XX-10

450-3367/450-3378/450-1807

Recommended hook-up wire size -

Sockets also accommodate

#22AWG, 7 strands #30 AWG copper wire PTFE insulated

#20 AWG, 7 strands #28 AWG copper wire

#24 AWG, 7 strands #32 AWG copper wire

450-0016/450-3413

Recommended hook-up wire size -

Sockets also accommodate

#20 AWG, 7 strands #28 AWG copper wire PTFE insulated

#18 AWG, 7 strands #26 AWG copper wire

#16 AWG, 19 strands #29 AWG copper wire

Recommended Crimp Pliers

450-3367-01

450-0016-01

Crimp tool Kit

435-5680-01-00-00

comprises of the following

Frame

430-5681-01-00-00

Turret head

430-5682-01-00-00

Crimp tool Kit

435-5699-01-00-00

comprises of the following

Frame

430-5681-01-00-00

Positioner

430-5684-01-00-00

450-1807-01

Call our dedicated order line on

+44 (0) 1433 621555

or visit

www.cambion.com

13
