Pin Strip |
Spacing 5.0 mm
STL950/..G-5.0-H-P2.6-BK-HC-HT
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
-
-
-
-
-
-
Order Data (Spacing 5.0 mm)
Insulating Material
Material
Flammability Class
PPA
2
11.20
16.20
21.20
26.20
31.20
36.20
41.20
46.20
51.20
56.20
61.20
STL950/2G-5.0-H-P2.6-BK-HC-HT
STL950/3G-5.0-H-P2.6-BK-HC-HT
STL950/4G-5.0-H-P2.6-BK-HC-HT
STL950/5G-5.0-H-P2.6-BK-HC-HT
STL950/6G-5.0-H-P2.6-BK-HC-HT
STL950/7G-5.0-H-P2.6-BK-HC-HT
STL950/8G-5.0-H-P2.6-BK-HC-HT
STL950/9G-5.0-H-P2.6-BK-HC-HT
STL950/10G-5.0-H-P2.6-BK-HC-HT
STL950/11G-5.0-H-P2.6-BK-HC-HT
STL950/12G-5.0-H-P2.6-BK-HC-HT
Poles
Width (mm)
Article Designation
Article
Number
50950025349 F
50950035349 F
50950045349 F
50950055349 E
50950065349 E
50950075349 E
50950085349 D
50950095349 D
50950105349 D
50950115349 D
50950125349 D
PU
200
200
200
100
100
100
50
50
50
50
50
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
Dimensions
PCB Hole Diameter
1.4 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
8
9
10
11
12
Materials
Contact Pin
Copper
Alloy
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
217 - 245 °C
Accessoires
60 s
Figure
Designation
Article Number
Colours
BLACK, RAL 9011
Colours according to RAL, there may be variations on colour due to production conditions.
Coding Star CS2-5.0/5.08-LIGHT Order Data: 50000000028
GREY-HT
Counterparts (Spacing 5.0 mm)
Terminal Block
AK950
In combination of connectors with different admission data, the lower value is valid.
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
16 A
C
150 V
16 A
D
300 V
10 A
250 V
16 A
III
1.60 kV
1.30 kV
1.60 kV
4.0 kV
3
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
