MKP1840-447-634 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> MKP1840-447-634

MKP1840-447-634: DescriptionCAPACITOR, METALLIZED FILM, POLYPROPYLENE, 630 V, 0.47 uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components capacitor; File Size80KB，4 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

MKP1840-447-634 Overview

CAPACITOR, METALLIZED FILM, POLYPROPYLENE, 630 V, 0.47 uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT

MKP1840-447-634 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	RATED AC VOLTAGE (V): 250
capacitance	0.47 µF
Capacitor type	FILM CAPACITOR
dielectric materials	POLYPROPYLENE
high	23.5 mm
JESD-609 code	e3
length	31.5 mm
Manufacturer's serial number	MKP1840
Installation features	THROUGH HOLE MOUNT
negative tolerance	5%
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
Package form	Radial
method of packing	BULK
positive tolerance	5%
Rated (AC) voltage (URac)	250 V
Rated (DC) voltage (URdc)	630 V
series	MKP 1840
surface mount	NO
Temperature Coefficient	-250ppm/Cel ppm/°C
Terminal surface	Tin (Sn)
Terminal pitch	27.5 mm
Terminal shape	WIRE
width	13.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

MKP 1840

Vishay Roederstein

AC and Pulse Metallized Polypropylene Film Capacitors

MKP Radial Potted Type

Dimensions in millimeters

max.

FEATURES

max.

• Compliant to RoHS Directive 2002/95/EC

Marking

CAPACITANCE TOLERANCES

max.

± 20 % (M), ± 10 % (K), ± 5 % (J)

RATED VOLTAGES (U

)

100 V

,160 V

, 250 V

, 400 V

, 630 V

0.6

± 0.4

Pitch

± 0.4

Ø 0.8

6-1

INSULATION RESISTANCE

Measured at 100 V

after one minute

For C

≤

0.33 µF:

25 000 MΩ (U

100 V

)

LEAD DIAMETER

(mm)

0.5

0.6

0.8

1.0

(mm)

< 16

≥

16.5

PITCH

(mm)

7.5/10

15 to 37.5

PERMISSIBLE AC VOLTAGES (RMS) UP TO 60 Hz

63 V

, 100 V

, 160 V

, 220 V

, 250 V

TEST VOLTAGE (ELECTRODE/ELECTRODE)

1.6 x U

for 2 s

MAIN APPLICATIONS

Pulse operations, deflection circuits in TV-sets

(S-correction), SMPS and thyristor circuits, storage, filter,

timing, sample and hold circuits.

TIME CONSTANT

Measured at 100 V

after one minute

For C > 0.33 µF:

30 000 s minimum value

DIELECTRIC

Polypropylene film

TEMPERATURE COEFFICIENT

- 250 x 10

-6

/°C (typical value)

ELECTRODES

Metallized

CAPACITANCE DRIFT

Up to + 40 °C, < 0.5 % for a period of two years

COATING

Flame retardant plastic case (class UL 94 V0), epoxy resin

sealed.

DIELECTRIC ABSORPTION

0.05 % (typical value) according to IEC 60068-2-21

CONSTRUCTION

LEADS

Tinned wire

Extended metallized film (refer to General Information)

DERATING FOR DC AND AC CATEGORY

VOLTAGE U

At + 85 °C: U

= 1.0 U

At + 100 °C: U

= 0.7 U

SELF INDUCTANCE

~ 6 nH measured with 2 mm long leads

IEC TEST CLASSIFICATION

55/100/56, according to IEC 60068

PULL TEST ON LEADS

≥

30 N in direction of leads according to IEC 60068-2-21

For further details, please refer to the general information

available at

www.vishay.com/doc?26033.

OPERATING TEMPERATURE RANGE

- 55 °C to + 100 °C

CAPACITANCE RANGE

4700 pF to 10 µF

MAXIMUM PULSE RISE TIME

PCM

(mm)

7.5

22.5

27.5

37.5

100 V

390

Maximum Pulse Rise Time dV/dt [V/µs]

160 V

250 V

400 V

240

300

175

100

125

200

120

630 V

510

280

160

120

Note

• If the maximum pulse voltage is less than the rated voltage higher dV/dt values can be permitted.

Document Number: 26061

Revision: 30-Nov-10

For technical questions, contact:

dc-film@vishay.com

www.vishay.com

147
