Assembly Instructions-C7R
BNC
Amphenol
®
2-PIECE CRIMP PLUGS
outer ferrule
plug body assembly
Amphenol
Number
31-5556-RFX
31-5557-RFX
31-5560-RFX
Connector
Type
BNC Plug
BNC Plug
BNC Plug
Cable
RG-/U
59, 62
58
Plenum 59, 62
Hex Crimp Data
Cavity for
Outer Ferrule
.324(8.2)
.324(8.2)
.324(8.2)
Die Set for
Tool 227-944*
227-1221-32
227-1221-32
227-1221-32
CTL Series
Tool Number
CTL-2
CTL-2
CTL-2
a
Stripping Dimensions, inches (mm)
b
.312(7.9)
.312(7.9)
.312(7.9)
c
.248(6.3)
.248(6.3)
.248(6.3)
d
.125(3.2)
.437(11.1)
.437(11.1)
.437(11.1)
Assembly
.125(3.2)
.125(3.2)
Step 1
a
Step 1
Strip cable jacket, braid, and dielectric to dimensions
in table above. All cuts are to be sharp and square.
Important: Do not nick braid, dielectric, and center
conductor. Slide outer ferrule onto cable as shown.
c
b
Step 2
Flare slightly end of cable braid as shown to facilitate
insertion of inner ferrule of connector. Important: Do not
comb out braid.
Step 2
Step 3
Install cable assembly into body assembly so that inner
ferrule portion slides under braid. Slide outer ferrule over
braid and up against connector body. Crimp outer ferrule
using Die Set Cavity specified in table above.
Step 3
Amphenol Corporation Tel: 800-627-7100
www.amphenolrf.com
279
Assembly Instructions-C25
BNC
CLAMP CONNECTORS
Amphenol
®
nut
washer*
gasket
clamp
bushing‡ female contact
jack body
male contact
plug body
* Not supplied on all items
‡ For use on RG-62, 71, 122, 178, 180, 196, 210
Stripping Dims,
Inches (Millimeters)
a
.490(12.4)
.490(12.4)
.343(8.7)
.297(7.5)
.405(10.3)
.156(3.96)
.250(6.4)
.540(13.7)
.281(7.1)
.281(7.1)
.265(6.73)
.313(7.95)
.266(6.75)
.312(7.9)
.315(8.0)
.297(7.54)
.274(6.95)
.297(7.54)
.297(7.5)
.297(7.54)
.250(6.4)
.250(6.4)
.375(9.52)
.250(6.4)
.250(6.4)
.250(6.4)
c
.200(5.1)
.200(5.1)
.187(4.7)
.094(2.4)
.094(2.4)
.078(1.98)
.094(2.4)
.156(3.96)
.172(4.4)
.172(4.4)
.156(3.96)
.203(5.15)
.109(2.76)
.094(2.4)
.118(3.0)
.109(2.75)
.094(2.4)
.109(2.8)
.109(2.8)
.209(2.75)
.094(2.4)
.094(2.4)
.125(3.17)
.094(2.4)
.094(2.4)
.094(2.4)
Amphenol
Number
6775
6775-75
8525
8575
9350
15875
16300
33275
69475
84975
86350
86425
86850
31-2
31-2-RFX
31-15
31-202
31-204
Connector
Type
BNC Plug
75Ω BNC Plug
BNC Angle Plug
BNC Angle Plug
BNC Plug
BNC Plug
BNC Plug
BNC Angle Plug
BNC Plug
BNC Plug
BNC Bulkh. Jack
BNC Panel Jack
BNC Bulkh. Jack
BNC Plug
BNC Plug
BNC Jack
BNC Plug
BNC Angle Plug
BNC Bulkhead Jack
BNC Bulkhead Jack
BNC Plug
BNC Plug
BNC Angle Plug
BNC Plug
BNC Plug
BNC Plug
Cable
RG-/U
8, 9, 11, 213, 214
11
58, 141, 142, 400
59, 62, 140, 210
6
178, 196
180
174, 179, 187, 188, 316
174, 179, 187, 188, 316
122
174, 179, 187, 188, 316
174, 179, 187, 188, 316
178, 196
58, 141, 142, 400
58, 141, 142A
59, 62, 71, 140, 210
55, 58, 141, 142, 223, 400
55, 58, 141, 142, 223, 400
58, 141, 142, 400
59, 62, 71, 140, 210
59, 62, 71, 140, 210, 302
59 (20GA CC)
59, 62, 71, 140, 210
55, 58, 141, 142, 223, 400
58, 141, 142, 223
59, 62, 71, 140, 210
Assembly
Step 1
31-206
31-207
31-212
a
31-212-1005
31-850
31-3202
31-3301
31-3302
c
Step 2
Step 3
Step 1
Place nut, washer (when supplied) and gasket over cable
and strip jacket to dimension
a
shown in table above.
Step 2
Comb out braid and fold out. Trim insulation off center
conductor to dimension
c
shown in table above. [For RG-62,
71 and 210/U cable, trim an additional .032"(0.8mm) of
insulation off center conductor and add bushing.] Tin
center conductor.
Step 3
Pull braid wires forward and taper toward center conductor.
Place clamp over braid and push back against cable
jacket.
Step 4
Fold back braid wires as shown, trim to proper length
[approximately .125" (3.2mm) long] and form over clamp
as shown. Braid wire should not extend beyond step of
braid clamp. Solder contact to center conductor, sliding
bushing first (when supplied) over center conductor.
v
Step 5
Insert cable and parts into connector body. Make sure
sharp edge of clamp seats properly in gasket. Tighten nut
to approximately 15 inch pounds.
www.amphenolrf.com
Step 4
Step 5
v
For angle plugs only:
(except 31-204) Solder center
conductor to preassembled contact. Assemble cap and
lightly punch center of cap for retention in body, or solder in
place.
Amphenol Corporation Tel: 800-627-7100
299
Assembly Instructions-C26
BNC
3-PIECE CRIMP PLUGS
outer ferrule
bushing
x
male contact
Amphenol
®
plug body assembly
x
used with RG-62, 71, 210 cable only
Amphenol
Number
36650-1003
36650-3RFX
36875
68175-1003
68175-1005
68175-1011
68175-11RFX
68175-5RFX
31-242
31-242-RFX
31-315
31-315-RFX
31-315-1005
31-320
31-320-RFX
31-320-1006
31-321
31-321-RFX
31-321-1000
31-321-10RFX
31-325
31-326
31-326-RFX
31-4320
31-4321
31-4411
31-4427
31-5558-RFX
31-5800
31-5900
Connector
Type
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
BNC Plug
Cable
RG-/U
Belden 82907, 88240
89907, Plenum 58
Plenum 58
55, 142, 223, 400
Belden 9259
59 (20AG CC)
Belden 1560A, 82259,
89259, Plenum 59, 62
Plenum 59, 62
59 (20GA CC)
179, 187
179, 187
174, 188, 316
174, 188, 316
Dbl. Br. 316
58, 141
58A, 141, 142A
Belden 9907, 89907
59, 62
59, 62
Belden 8281, 88281
Belden 8281
Belden 8218
55, 142, 223
55, 142, 223, 400
58, 141
59, 62
Belden 8213
142, 400
6 Type (.314OD)
58, 141, PL-58
59, 62, 59 (20GA CC),
Plenum -59, 62
a
b
c
Hex Crimp Data
Cavity for
Contact
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
.100(2.5)
.068(1.7)
.068(1.7)
.068(1.7)
.068(1.7)
Cavity for
Outer Ferrule
.178(4.5)
.213(5.4)
.213(5.4)
.255(6.5)
.255(6.5)
.255(6.5)
.255(6.5)
.255(6.5)
.178(4.5)
.178(4.5)
.178(4.5)
.178(4.5)
.178(4.5)
.213(5.4)
.213(5.4)
.213(5.4)
.255(6.5)
.255(6.5)
.324(8.2)
.324(8.2)
.178(4.5)
.213(5.4)
.213(5.4)
.213(5.4)
.255(6.5)
.429(10.9)
.213(5.4)
.324(8.2)
.213(5.4)
.255(6.5)
Die Set for
Tool 227-944*
227-1221-9
227-1221-11
227-1221-11
227-1221-13
227-1221-13
227-1221-13
227-1221-13
227-1221-13
227-1221-9
227-1221-9
227-1221-9
227-1221-9
227-1221-9
227-1221-11
227-1221-11
227-1221-11
227-1221-13
227-1221-13
227-1221-32
227-1221-32
227-1221-9
227-1221-11
227-1221-11
227-1221-11
227-1221-13
227-1221-25
227-1221-11
227-1221-32
227-1221-11
227-1221-13
CTL Series
Tool Number
CTL-2
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-2
CTL-2
CTL-2
CTL-2
CTL-2
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-2
CTL-2
CTL-2
CTL-1
CTL-1
CTL-1
CTL-1
CTL-3
CTL-1
CTL-2
CTL-1
CTL-1
Stripping Dimensions, inches (mm)
a
.593(15.1)
.630(16.0)
.593(15.1)
.593(15.1)
.593(15.1)
.593(15.1)
.630(16.0)
.630(16.0)
.593(15.1)
.590(15.0)
.593(15.1)
.593(15.1)
.593(15.1)
.593(15.1)
.630(16.0)
.593(15.1)
.593(15.1)
.630(16.0)
.593(15.1)
.630(16.0)
.593(15.1)
.593(15.1)
.593(15.1)
.593(15.1)
.593(15.1)
.650(16.5)
.593(15.1)
.630(16.0)
.593(15.1)
.593(15.1)
b
.250(6.4)
.319(8.1)
.250(6.4)
.250(6.4)
.250(6.4)
.250(6.4)
.303(7.7)
.303(7.7)
.250(6.4)
.323(8.2)
.250(6.4)
.250(6.4)
.250(6.4)
.250(6.4)
.303(7.7)
.250(6.4)
.250(6.4)
.303(7.7)
.250(6.4)
.303(7.7)
.250(6.4)
.250(6.4)
.250(6.4)
.250(6.4)
.250(6.4)
.250(6.4)
.250(6.4)
.303(7.7)
.250(6.4)
.250(6.4)
c
.156(4.0)
.157(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.157(4.0)
.157(4.0)
.156(4.0)
.118(3.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
Step 1
s
Step 2
Step 3
cable dielectric must butt insulator
outer ferrule should butt here
v
contact must butt against cable dielectric
crimp here
Step 1
Strip cable jacket, braid, and dielec-
tric to dimensions in table above. [for RG-
62,71,210/U cable, trim an additional
.039"(1.0mm) of insulation off center conduc-
tor and add bushing] All cuts are to be sharp
and square.
Important: Do not nick braid, dielectric, and
center conductor. Slide outer ferrule onto
cable as shown.
Step 2
Flare slightly end of cable braid as
shown to facilitate insertion of inner ferrule.
Important: Do not comb out braid
v
.
Place contact on cable center conductor so
that it butts against cable dielectric. Crimp
contact in place using Die Set Cavity indicat-
ed in table above. When using RG-62, 71,
210 cable, install bushing over center con-
ductor before installing contact.
Step 3
Install cable assembly into body
assembly so that inner ferrule portion slides
under braid. Push cable assembly forward
until contact snaps into place in insulator.
Slide outer ferrule over braid and up against
connector body. Crimp outer ferrule using
Die Set Cavity specified in table above.
s v
For RG-174, 179, 187, 188, 316/U cables only, slit jacket back .100"(2.5mm)
as shown. Before attaching center contact, slide metal spacer/TFE sleeve
(not shown) over cable dielectric and under braid. The center contact
should butt against the dielectric and TFE sleeve.
* for pneumatic crimp tool 227-60, use die sets indicated in this column.
www.amphenolrf.com
Amphenol Corporation Tel: 800-627-7100
300
Assembly Instructions-C26a
BNC
3-PIECE CRIMP ANGLE PLUGS & BULKHEAD JACKS
Amphenol
®
outer ferrule
bushing
x
male contact
plug body assembly
x
used with RG-62, 71, 210 cable only
Amphenol
Number
36800
36800-RFX
68150
95700
31-245
31-316
31-317
31-318
31-318-RFX
31-318-1001
31-245-RFX
31-334
31-335
31-335-RFX
31-336
31-336-RFX
31-342
31-342-RFX
31-343-1002
31-343-RFX
31-4327
31-5911-RFX
31-5914-RFX
31-5991-RFX
31-316-RFX
31-70239
31-70240
31-70234
31-70235
31-70236
31-70237
31-70238
31-315-RFX
31-317-RFX
31-335-RFX
31-5998-RFX
31-5999-RFX
31-6004-RFX
31-6005-RFX
31-6006
Step 1
Connector
Type
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
BNC
Jack
Jack
Jack
Bulkh. Jack
Bulkh. Jack
Angle Plug
Jack
Bulkh. Jack
Bulkh. Jack
Bulkh. Jack
Bulkh. Jack
Angle Plug
Angle Plug
Angle Plug
Angle Plug
Angle Plug
Bulkh. Jack
Bulkh. Jack
Bulkh. Jack
Bulkh. Jack
Jack
Angle Plug
Angle Plug
Angle Plug
Angle Plug
Angle Plug
Angle Plug
Plug
Plug
Plug
Plug
Plug
Plug
Jack
Angle Plug
Plug
Plug
Angle Plug
Angle Plug
Plug
s
a
Cavity for
Contact
58, 141
.068(1.7)
58, 141
.068(1.7)
59, 62, 140
.068(1.7)
55, 142, 223
.068(1.7)
179, 187
.068(1.7)
174, 188, 316
.068(1.7)
174, 188, 316
.068(1.7)
174, 188, 316
.068(1.7)
174, 188, 316
.068(1.7)
Dbl. Br. 316
.068(1.7)
179, 187
.068(1.7)
55, 142, 223, 400 .068(1.7)
58, 141
.068(1.7)
58, 144
.068(1.7)
59, 62
.068(1.7)
59, 62
.068(1.7)
58, 141
.068(1.7)
58, 141, 142, 223 .068(1.7)
Pl. 59 (20 AWG)
.068(1.7)
59, 62, 140, 210
.068(1.7)
58, 141
.068(1.7)
58,141
Solder
59
Solder
316
Solder
316
Solder
734A
.042
735A
.042
Beld 1694
.042
Beld 8281
.042
Beld 8218
.042
734A
.042
735A
.042
174,188,316
.068
174,188,316
.068
58,141,142
.068
B8214,B9913,B9914 .118
8x,LMR240
.068
B9913,B9914
Solder
8x,LMR240
Solder
8x,LMR240
.068
Cable
RG-/U
Hex Crimp Data
Cavity for
Outer Ferrule
.213(5.4)
.213(5.4)
.255(6.5)
.213(5.4)
.178(4.5)
.178(4.5)
.178(4.5)
.178(4.5)
.178(4.5)
.178(4.5)
.178(4.5)
.213(5.4)
.213(5.4)
.213(5.4)
.255(6.5)
.255(6.5)
.213(5.4)
.213(5.4)
.255(6.5)
.255(6.5)
.213(5.4)
.213
.255
.128
.128
.255
.187
.319
.324
.178
.255
.187
.178
.178
.213
.429
.255
.429
.255
.255
Die Set for
Tool 227-944*
227-1221-11
227-1221-11
227-1221-13
227-1221-11
227-1221-9
227-1221-9
227-1221-9
227-1221-9
227-1221-9
227-1221-9
227-1221-9
227-1221-11
227-1221-11
227-1221-11
227-1221-13
227-1221-13
227-1221-11
227-1221-11
227-1221-13
227-1221-11
227-1221-11
227-1221-11
227-1221-13
227-1221-3
227-1221-3
—
—
—
—
—
—
—
227-1221-9
227-1221-9
227-1221-11
227-1221-61
227-1221-13
227-1221-25
227-1221-13
227-1221-13
CTL Series
Tool Number
CTL-1
CTL-1
CTL-1
CTL-1
CTL-2
CTL-2
CTL-2
CTL-2
CTL-2
CTL-2
CTL-2
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1
CTL-1,3,5
CTL-1,5,6,8
CTL-9,13
CTL-9,13
CTL-14
CTL-15
CTL-14
CTL-14
CTL-15
CTL-14
CTL-15
CTL-2
CTL-2
CTL-1,5
CTL-11
CTL-1,5
CTL-4
CTL-1,5
CTL-1,5
Stripping Dimensions, inches (mm)
a
.593(15.1)
.630(16.0)
.593(15.1)
.593(15.1)
.593(15.1)
.578(14.6)
.593(15.1)
.593(15.1)
.630(16.0)
.593(15.1)
.630(16.0)
.578(14.6)
.578(14.7)
.677(17.2)
.578(14.7)
.677(17.2)
.593(15.1)
.689(17.5)
.593(15.1)
.689(17.5)
.593(15.1)
.709(18.0)
.709(18.0)
.618(15.7)
.618(15.7)
.630 (16.0)
.630 (16.0)
.630 (16.0)
.630 (16.0)
.630 (16.0)
.630 (16.0)
.630 (16.0)
.593 (15.1)
.634 (16.1)
.677 (17.2)
.630 (16)
.630 (16)
.728 (18.5)
.728 (18.5)
.593 (15.1)
b
.250(6.4)
.303(7.7)
.250(6.4)
.250(6.4)
.250(6.4)
.328(8.3)
.250(6.4)
.250(6.4)
.362(9.2)
.250(6.4)
.362(9.2)
.328(8.3)
.328(8.3)
.350(8.9)
.328(8.3)
.350(8.9)
.250(6.4)
.362(9.2)
.250(6.4)
.362(9.2)
.250(6.4)
.382(9.7)
.382(9.7)
.350(8.9)
.350(8.9)
.303 (7.7)
.303 (7.7)
.303 (7.7)
.303 (7.7)
.303 (7.7)
.303 (7.7)
.303 (7.7)
.250 (6.4)
.303 (7.7)
.350 (8.9)
.303 (7.7)
.303 (7.7)
.401 (10.2)
.401 (10.2)
.250 (6.4)
c
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.125(3.1)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.156(4.0)
.125(3.1)
.125(3.2)
156(4.0)
.125(3.2)
.156(4.0)
.156(4.0)
.157(4.0)
.156(4.0)
.157(4.0)
.156(4.0)
.161(4.1)
.161(4.1)
.157(4.0)
.157(4.0)
.157 (4.0)
.157 (4.0)
.157 (4.0)
.157 (4.0)
.157 (4.0)
.157 (4.0)
.157 (4.0)
.156 (4.0)
.156 (4.0)
.157 (4.0)
.157 (4.0)
.157 (4.0)
.244 (6.2)
.244 (6.2)
.156 (4.0)
Assembly
b
c
v
s v
For RG-174, 179, 187, 188, 316/U cables only, slit jacket back .100"(2.5mm)
as shown. Before attaching center contact, slide metal spacer/TFE sleeve
(not shown) over cable dielectric and under braid. The center contact
should butt against the dielectric and TFE sleeve.
Step 1
Strip cable jacket, braid, and dielectric to dimensions in table above. [for
RG-62,71,210/U cable, trim an additional .039"(1.0mm) of insulation off
center conductor and add bushing] All cuts are to be sharp and square.
Important: Do not nick braid, dielectric, and center conductor. Slide
outer ferrule onto cable as shown.
Step 2
Flare slightly end of cable braid as shown to facilitate insertion of inner fer-
rule. Important: Do not comb out braid
v
.
Place contact on cable center
conductor so that it butts against cable dielectric. Crimp contact in place
using Die Set Cavity indicated in table above. When using RG-62, 71,
210 cable, install bushing onto center conductor before installing contact.
Step 3
Install cable assembly into body assembly so that inner ferrule portion
slides under braid. Push cable assembly forward until contact snaps into
place in insulator. Slide outer ferrule over braid and up against connector
body. Crimp outer ferrule using Die Set Cavity specified in table
above.
* for pneumatic crimp tool 227-60, use die sets indicated in this column
Step 2
contact must butt against cable dielectric
Step 3
cable dielectric must butt insulator
outer ferrule should butt here
crimp here
Amphenol Corporation Tel: 800-627-7100
www.amphenolrf.com
301
Assembly Instructions-C26b
BNC
ORIGINAL CRIMP PLUGS
Amphenol
®
BOOT
OUTER FERRULE
FERRULE/
CLAMP NUT ASSY
G O
SS
boot
ferrule
ferrule clamp
nut assembly
plug body assembly
Amphenol
Number
31-351
31-359
31-371
Connector
Type
BNC Plug
BNC Plug
BNC Plug
58, 141
Cable
RG-/U
Hex Crimp Data
Cavity for
Contact
—
—
—
Cavity for
Outer Ferrule
.213(5.4)
.255(6.5)
.128(3.2)
Die Set for
Tool 227-944*
227-1221-11
227-1221-13
227-1221-3
Stripping Dimensions, inches (mm)
a
.922(23.4)
.922(23.4)
.797(20.2)
b
.516(13.1)
.516(13.1)
.516(13.1)
c
.250(6.3)
.250(6.3)
.250(6.3)
59, 62, 140
174, 179, 187, 188, 316
Step 1
STEP 1
boot
outer ferrule
Step 1
Install boot and slide outer ferrule onto cable as shown prior
to stripping cable.
Step 2
Strip cable jacket, braid and dielectric to dimensions shown.
See attached table for dimensions. All cuts are to be sharp
and square. Important: DO NOT nick braid, dielectric, and
center conductor when cutting. Tin center conductor using
soft solder per QQ-S-571 comp Sn 60. Avoid excessive heat
while tinning to prevent swelling of cable dielectric.
a
Step 2
STEP 2
b
c
Step 3
P3
Step 3
Slightly flare out end of cable braid as so as to facilitate
insertion onto ferrule clamp nut assembly. Important:
DO NOT comb out braid.
Step 4
STEP 4
outer ferrule must
clamp nut assy
as shown
cable dielectric must
butt insulator as shown
Step 5
STEP 5
note: center conductor must
be visible thru contact solder
hole prior to soldering
Step 4
Install ferrule clamp nut assembly onto cable so that ferrule
portion slides under braid and insulator butts flush against
cable dielectric. Slide outer ferrule over braid and up
against nut. Make sure no slack exists in braid. Crimp outer
ferrule with tool specified in table above, keeping cable
dielectric bottomed against insulator.
Step 6
STEP 6
Step 5
Soft solder center conductor to contact using rosin core per
QQ-S-571 comp Sn 60. DO NOT get any solder on outside
surfaces of contact.
Step 7
STEP 7
lip of boot must be firmly posi-
tioned in body groove
Step 6
Screw connector body onto prepared cable termination .
Wrench tighten by holding the cable nut assembly
STATIONARY while ROTATING the connector body.
Step 7
Push body forward and into position as shown to complete
assembly.
* for pneumatic crimp tool 227-60, use die sets indicated in this column
Amphenol Corporation Tel: 800-627-7100
www.amphenolrf.com
302
京公网安备 11010802033920号
EEWORLD
