SMV30222-06 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> SMV30222-06

SMV30222-06: DescriptionVariable Capacitance Diode, 6pF C(T), 8V, Silicon, Hyperabrupt, PLASTIC PACKAGE-2; CategoryDiscrete semiconductor diode; File Size36KB，1 Pages; ManufacturerCobham PLC

Download Datasheet Parametric View All

SMV30222-06 Overview

Variable Capacitance Diode, 6pF C(T), 8V, Silicon, Hyperabrupt, PLASTIC PACKAGE-2

SMV30222-06 Parametric

Parameter Name	Attribute value
Maker	Cobham PLC
package instruction	R-PDSO-G2
Reach Compliance Code	unknown
ECCN code	EAR99
Minimum breakdown voltage	8 V
Configuration	SINGLE
Diode Capacitance Tolerance	16.67%
Nominal diode capacitance	6 pF
Diode component materials	SILICON
Diode type	VARIABLE CAPACITANCE DIODE
JESD-30 code	R-PDSO-G2
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.25 W
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	8 V
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Varactor Diode Classification	HYPERABRUPT
Base Number Matches	1

Preview

Download Datasheet

View All

Surface Mount 3022 / 3033 SERIES Varactor

SUPER HYPERABRUPT TUNING DIODES

FOR VCXO’S

•

Extremely High Capacitance Swing

•

Linear Characteristics

•

Uniform Capacitance / Temperature Coefficient

•

Highly Reproducible Ion Implanted Structure

Designed for 3 and 5 volt circuits

PART

@ 1.0 VOLT

@ 2.5 VOLT

@ 4 VOLT

@ 4 VOLTS

NUMBER

♦♦♦

SMV30222

SMV30223

SMV30224

SMV30225

(pF)

MIN

(pF)

MIN

MAX

(pF)

MAX

2.4

4.8

7.2

9.6

50 MHz

MAX

4.0

Ω

2.3

Ω

1.9

Ω

1.5

Ω

AVAILABLE

IN THE FOLLOWING

PACKAGES

-01, -06, -07, -08, -09, -10

-01, -06, -07, -08, -09

Designed specifically for 3 volt circuits

PART

@ 0.3 V / C

@ 1.65 V

@ 1.65 VOLT

@ 1.65 V / C

@ 3.0 V

@ 1.65 VOLTS

NUMBER

♦♦♦

SMV30332

SMV30333

RATIO

MIN TYP

3.0

4.0

3.0

4.0

( pF)

MIN

MAX

5.5

7.0

11.0

14.0

RATIO

MIN

TYP

3.0

4.0

3.0

4.0

50 MHz

MAX

16.0

Ω

9.0

Ω

AVAILABLE

IN THE FOLLOWING

PACKAGES

-01, -06, -07, -08, -09, -10

Reverse Breakdown Voltage (VBR)

Max Reverse Leakage Current (IR)

Device Dissipation (PD)

Operating Temperature (Topr)

Storage Temperature (Tstg)

10 µAdc

VR = 6 Volts

Ta = 25°C

8 Volt Min

0.1 µAdc

250 mW

-55° to +125°C

-65° to +150°C

♦♦♦

Package Styles

Requires adding a dash suffix number to the part number

SOT23 Single

SOT23 Common Anode

SOT23 Common Cathode

SOD323

SOD523 (SC79, SC90)

CHIPS

-08

-09

-10

-06

-07

-01

P.O. BOX 609

•

ROCKPORT, MAINE 04856

•

207-236-6076

•

FAX 207-236-9558
