Product Bulletin
OC-3 Small Form Factor
(SFF) Transceiver
CF2 Series
The JDS Uniphase CF2 Series OC-3 transceiver is
a duplex-LC transceiver designed for use in
SONET OC-3 and SDH STM-1 applications. It
operates with a single 3.3 V power supply. The
unit conforms to the industry-standard 2x5 and
2x10 footprints and meets the mezzanine height
requirement of 9.8 mm.
Each transceiver consists of an optical
subassembly housing both the transmitter and
the receiver, and an electrical subassembly. All
are packaged together with a top metal cover and
bottom shield.
The optical subassembly comprises two parts:
the transmitter side has a high-performance
1300 nm Fabry-Perot (FP) or 1550 nm
distributed feedback (DFB) laser and back facet
monitor. The receiver side has an InGaAs PIN
and a preamplifier.
All CF2 Series OC-3 transceivers also include a
signal detect circuit, which provides either a
Positive Emitter Coupled Logic (PECL) or TTL
logic high output when a usable input optical
signal level is detected.
Key Features
•
Temperature ranges: 0 to 70 °C, -20 to 85 °C,
and -40 to 85 °C
•
Single 3.3 V power supply
•
LV-PECL data input and receiver output levels
•
TTL or PECL signal detect
•
Multisource Agreement (MSA)-conforming
2x5 and 2x10 SFF package
•
Electromagnetic interference (EMI) meets FCC
Class B limit
•
Class 1 Laser Safety conformance
•
Meets mezzanine height standard of 9.8 mm
•
Wave-solderable/aqueous-washable
•
Industry-standard duplex-LC optical connector
•
Operates with 9/125 µm single-mode optical fibers
•
Available in IR1 (15 km), LR1 (40 km), and
LR2 (80 km) reaches
Applications
•
Metro
•
Access
•
Wide area networks
Compliance
•
Compliant with SONET OC-3 and ITU-T
G.957 SDH STM-1 specifications (155 Mb/s
data rate)
OC-3 SFF Transceiver | 2
2x5 SFF Transceiver Dimensions Diagram
(Specifications in mm [inches] unless otherwise noted.)
Bezel Opening Dimensions Diagram
(Specifications in mm [inches] unless otherwise noted.)
14.22 ± 0.1
[0.560±0.004]
2.50 [0.098] MAX
1.00 [0.039] MIN
10.16 ± 0.1
[0.400±.004]
15.75 [0.620] MAX
15.00 [0.590] MIN
OC-3 SFF Transceiver | 3
2x5 PCB Layout
(Specifications in mm [inches] unless otherwise noted.)
Hole Sizes
PIN 10
B
A
A
1.78
[0.070]
PIN 6
Symbol
A
B
C
Quantity
2
4
10
Diameter
1.40±0.1 mm (0.055±0.004 inches)
1.40±0.1 mm (0.055±0.004 inches)
0.81±0.1 mm (0.032±0.004 inches)
13.34
[0.525]
10.16
[0.400]
CCCCC
CCCCC
B
B
B
1.59
[0.063]
4.57
[0.180]
PIN 5
7.11
[0.280]
17.78
[0.700]
28.45
[1.120]
PIN 1
TOP VIEW
Transceiver Pin Descriptions (2x5 Configuration)
Pin
Symbol
Description
The mounting posts are provided for transceiver mechanical attachment to the circuit board.
They should not be connected to the circuit ground but can be connected to the chassis ground.
The housing leads should be connected to the circuit ground.
Receiver signal ground
3.3 V receiver power supply
Signal detect is a TTL output. A high level indicates a valid optical signal.
Receiver data inverted differential output
Receiver data non-inverted differential output
3.3 V transmitter power supply
Transmitter signal ground
Transmitter disable
Transmitter data non-inverted differential input
Transmitter data inverted differential input
Mounting posts
Housing leads
1
V
EER
2
3
4
5
6
7
8
9
10
V
CCR
SD
RD-
RD+
V
CCT
V
EET
TX
dis
TD+
TD-
Transceiver Pin Descriptions (2x10 Configuration)
Pin
Symbol
Description
Pin
Symbol
Description
Mounting posts
Housing leads
1
2
3
4
5
6
7
8
9
10
V
pd
V
EER
V
EER
NA
NA
V
EER
V
CCR
SD
RDb
RD
The mounting posts are provided for transceiver mechanical attachment to the circuit board.
They should not be connected to the circuit ground but can be connected to the chassis ground.
The housing leads should be connected to the circuit ground.
Rx photo detector bias
Rx ground
Rx ground
Not used
Not used
Rx ground
Rx power
Signal detect
Rx electrical data
Rx electrical data
11
12
13
14
15
16
17
18
19
20
V
CCT
V
EET
TX_DIS
TD
TDb
V
EET
Bmon-
Bmon+
Pmon-
Pmon+
Tx power
Tx ground
Transmitter disable
Tx electrical data
Tx electrical data
Tx ground
Tx LD bias monitor
Tx LD bias monitor
Tx rear facet monitor
Tx rear facet monitor
OC-3 SFF Transceiver | 4
Absolute Maximum Ratings
Parameter
Storage temperature
Soldering temperature (6 sec. on leads)
Supply voltage
Symbol
T
S
V
CC
Minimum
-40 °C
-
-
Maximum
85 °C
260 °C
3.6 V
Operating Conditions
Parameter
Ambient operating temperature
Version A (IR1 and LR1 only)
Version B
Version C (LR2 only)
Supply voltage
Transmitter differential input voltage
Transmit disable input volt (low )
Transmit disable input volt (high)
Symbol
T
OP
-40 °C
0 °C
-20 °C
3.1 V
0.6 V
-
2.3 V
85 °C
70 °C
85 °C
3.5 V
2.0 V
0.3 V
-
Minimum
Maximum
V
CC
V
D
TD
Lo
TD
Hi
Electrical Specifications (Over specified T
OP
range, V
CC
= 3.1 to 3.5 V)
Parameter
Transmitter
Supply current
IR1 option
LR1 and LR2 options
Receiver
Supply current
Data output voltage swing (differential)
Data output rise and fall times (10 to 90% )
Total signal detect output (high)
Total signal detect output (low )
I
CCR
V
diff
t
r
,t
f
V
oh
,TTL
V
ol
,TTL
-
0.5 V
-
2.0 V
0.0 V
130 mA
1.9 V
2.2 ns
Vcc
0.8 V
Symbol
Minimum
Maximum
I
CCT
-
-
150 mA
170 mA
OC-3 SFF Transceiver | 5
Optical Specifications (Over specified T
OP
range, V
CC
= 3.1 to 3.5 V)
Parameter
Transmitter
Output optical power 9/125 µm, na = 0.10 fiber
IR1 option
LR1 and LR2 options
Optical extinction ratio
IR1 option
LR1 and LR2 options
Center wavelength
IR1 option
LR1 option
LR2 option
Spectral width
IR1 option (rms)
LR1 option (rms)
LR2 options (20 dB)
SMSR (LR1 and LR2 options)
Optical rise/fall time (10 to 90%)
Output optical eye
Receiver
Minimum optical input power (sensitivity)
IR1 option
LR1 and LR2 options
Maximum optical input power (saturation)
IR1 option
LR1 and LR2 options
Operating center wavelength
Signal detect (deasserted)
IR1 option
LR1 and LR2 options
Signal detect (asserted)
IR1 option
LR1 and LR2 options
Signal detect (hysteresis)
Symbol
Minimum
Maximum
P
OUT
-15 dBm avg.
-5 dBm avg.
8.2 dB
10.0 dB
λc
1261 nm
1263 nm
1480 nm
σ
σ
σ
20
t
r
/t
f
-
-
1360 nm
1360 nm
1580 nm
4 nm
3 nm
-8 dBm avg.
0 dBm avg.
-
-
-
1 nm
30 dB
-
-
2.2 ns
Conforms to eye mask Bellcore TR-NWT-000253
P
IN
-
-
P
IN
-8 dBm avg.
-10 dBm avg.
1265 nm
-
-
P
D
-42 dBm avg.
-48 dBm avg.
P
A
-P
D
1.0 dB
-
-
5.0 dB
-
-
1625 nm
-28 dBm avg.
-34 dBm avg.
-28 dBm avg.
-34 dBm avg.
λc
P
A
