T1 Right Angle LED Bar
Special Features
.122˝ High LED Centerline*
-
RoHS Compliant
*Patented
• Customized to your specifications without tooling charges
Variable LED spacing, minimum .180˝, maximum bar length 6˝
Variable color sequence
• Available with 2 to 33 T1 LEDs in one convenient assembly
• Bar provides consistent alignment for multiple LED mounting
• Available with a variety of LEDs
• Bottom standoff facilitates board washing
• Wave solderable and chemically cleanable
• Housing and bar material UL 94V-0 rated
3mm PC Board Mount LEDs
Electrical and Optical Characteristics (TA=25°C)
LED
Part#
Color
Luminous
Intensity (mcd)
Typ.@IF(mA)
VF Typ.@IF (mA)
Viewing
Angle
2Θ
2
Peak
More
Wavelength LED Data
(mm)
Page#
Package Dimensions
6.0" MAX
(152.4)
HIGH EFFICIENCY
1300
1301
1302
1313
Yellow
Red
Green
Orange
6.0
5.5
5.0
5.5
10
10
10
10
2.0
1.9
2.1
1.9
10
10
10
10
60°
60°
60°
60°
583
635
565
600
21
21
21
21
.180"
MIN
(4.6)
LOW CURRENT
1303
1304
1305
Red
Yellow
Green
2.1
1.6
2.1
2
2
2
1.8
1.9
1.8
2
2
2
50°
50°
50°
635
583
565
22
22
22
.265 (6.73)
.270
MAX
(6.9)
.180
(4.6)
.120 DIA.
(3.0)
.125
(3.2)
5V INTERNAL RESISTOR
1307
1308
1309
Red
Yellow
Green
8.0
8.0
8.0
10
10
10
5.0
5.0
5.0
10
10
10
60°
60°
60°
635
583
565
23
23
23
122
.122 (3.1) (3.1)
.135 .135
(3.4) (3.4)
.150
(3.8)
.195
(4.9)
CATHODE TO RIGHT
(Red/Yellow
cathode for bicolor)
BLUE
8310
8311
Blue
Blue
25.0
55.0
20
20
4.5
4.5
20
20
60°
20°
430
430
30
30
.100
(2.5)
BICOLOR
8901
8903
Red
Green
Yellow
Green
20.0
20.0
10.0
20.0
20
20
20
20
2.0
2.2
2.1
2.2
20
20
20
20
60°
60°
625
565
590
565
27
27
All Dimensions are in inches (mm)
Standard Polarity shown in drawing: Cathode right
How To Order
INDIVIDUAL RA LEDs
ULTRA BRIGHT
1310
1311
1312
1315
Red
Yellow
Green
Red
45.0
45.0
45.0
45.0
20
20
20
20
1.9
2.1
2.2
1.8
20
20
20
20
45°
45°
45°
60°
635
583
565
645
21
21
21
21
R A x — x x x x — 3000
LED Color
Red = R
Yellow = Y
Green = G
Orange = O
Bicolor = B
Blue = L
Housing
(See LED Chart)
SUPER ULTRA BRIGHT
8306
8312
8313
Green
Yellow
Red
200.0
700.0
800.0
20
20
20
2.2
2.0
1.85
20
20
20
50°
50°
50°
565
595
660
29
29
29
MULTIPLE RA LEDs ON A BAR
x R A x — x x x x — x x x — 3000
Number of
LED Color
LEDs
Red = R
Per Bar Yellow = Y
Green = G
Orange = O
Bicolor = B
Blue = L
Multiple = M
Center to Center
Spacing of LEDs
in inches
(If spacing varies,
use SPL)
Housing
See LED Chart
For Part #
(Use MCOO for
multiple colors)
Note: Consult factory if your color sequence and/or spacing varies.
®
