March 6, 2007
SMD INDUCTOR DR349-6 SERIES
Features
SMD Inductor
Suitable for Reflow soldering
Inductance Range from 0.01µH to 100µH
Operating Temp. -40°C to +85°C
Tinned Leads with Leaded Solder is Available
(note 4)
ELECTRICAL SPECIFICATIONS AT 25ºC
PART NO.
DR349-6-100
DR349-6-120
DR349-6-150
DR349-6-180
DR349-6-220
DR349-6-270
DR349-6-330
DR349-6-390
DR349-6-470
DR349-6-560
DR349-6-680
DR349-6-820
DR349-6-101
DR349-6-121
DR349-6-151
DR349-6-181
DR349-6-221
DR349-6-271
DR349-6-331
DR349-6-391
DR349-6-471
DR349-6-561
DR349-6-681
DR349-6-821
DR349-6-102
DR349-6-122
DR349-6-152
DR349-6-182
DR349-6-222
DR349-6-272
DR349-6-332
DR349-6-392
DR349-6-472
DR349-6-562
DR349-6-682
DR349-6-822
INDUCTANCE (µH)
@ 0A
@100MHz
0.010±20%
@100MHz
0.012±20%
@100MHz
0.015±20%
@100MHz
0.018±20%
@100MHz
0.022±20%
@100MHz
0.027±20%
@100MHz
0.033±20%
@100MHz
0.039±20%
@100MHz
0.047±20%
@100MHz
0.056±20%
@100MHz
0.068±20%
@100MHz
0.082±20%
@100MHz
0.100±20%
@25.2MHz
0.120±20%
@25.2MHz
0.150±20%
@25.2MHz
0.180±20%
@25.2MHz
0.220±20%
@25.2MHz
0.270±20%
@25.2MHz
0.330±20%
@25.2MHz
0.390±20%
@25.2MHz
0.470±20%
@25.2MHz
0.560±20%
@25.2MHz
0.680±20%
@25.2MHz
0.820±20%
@7.96MHz
1.000±10%
@7.96MHz
1.200±10%
@7.96MHz
1.500±10%
@7.96MHz
1.800±10%
@7.96MHz
2.200±10%
@7.96MHz
2.700±10%
@7.96MHz
3.300±10%
@7.96MHz
3.900±10%
@7.96MHz
4.700±10%
@7.96MHz
5.600±10%
@7.96MHz
6.800±10%
@7.96MHz
8.200±10%
DCR (Ω) MAX.
0.26
0.27
0.31
0.34
0.38
0.42
0.46
0.50
0.56
0.65
0.70
0.75
0.80
0.37
0.42
0.46
0.52
0.56
0.60
0.65
0.68
0.75
0.85
1.00
1.10
1.20
1.30
1.45
1.55
1.70
1.90
2.10
2.30
2.50
2.70
3.05
MAX. RATED CURRENT
(mA) TYP.
530
500
480
450
420
410
400
380
360
340
320
300
280
520
480
460
430
420
400
375
350
325
300
260
245
230
220
210
200
195
185
180
175
170
165
160
DATATRONIC
:
28151 Highway 74, Romoland, CA 92585
Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong KongTel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice
March 6, 2007
PART NO.
INDUCTANCE (µH)
@ 0A
DCR (Ω) MAX.
MAX. RATED CURRENT
(mA) TYP.
DR349-6-103
DR349-6-123
DR349-6-153
DR349-6-183
DR349-6-223
DR349-6-273
DR349-6-333
DR349-6-393
DR349-6-473
DR349-6-563
DR349-6-683
DR349-6-823
DR349-6-104
10.00±10%
12.00±10%
15.00±10%
18.00±10%
22.00±10%
27.00±10%
33.00±10%
39.00±10%
47.00±10%
56.00±10%
68.00±10%
82.00±10%
100.0±10%
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@2.52MHz
@0.796MHz
3.50
3.80
4.40
4.80
5.50
6.30
7.10
9.50
11.10
12.10
16.60
19.00
21.00
155
150
140
130
125
115
110
90
80
75
70
65
60
MECHANICAL OUTLINES
DR349-6
TOP VIEW
2.50
±
0.20
2.00
±
0.20
1.80
±
0.20
0.40
FRONT VIEW
1.50
1.40
SIDE VIEW
2.00
1.20
PCB SOLDER
PAD LAYOUT (REF.)
NOTES:
1. All dimensions are shown in millimeters “mm”.
2. General tolerance
±0.1mm
unless otherwise specified.
3. Tape and reel quantity, 1500 pcs/reel
4. For non-RoHS parts replace DR prefix with 42- (e.g. DR349-6 becomes 42-349-6).
5. Terminal finish is compliant to RoHS requirements. Solder in accordance with J-STD-020C.
DATATRONIC
:
28151 Highway 74, Romoland, CA 92585
Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong KongTel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice.
