DR349-2-152: DescriptionSMD INDUCTOR; File Size59KB，2 Pages; ManufacturerDATATRONICS; Websitehttp://www.datatronics.com/

Download Datasheet View All

DR349-2-152 Overview

SMD INDUCTOR

Preview

Download Datasheet

View All

July 13, 2007

SMD INDUCTOR DR349-2 SERIES

Features

Low Profile Surface Mount Design

Suitable for Reflow Soldering

Inductance Range from 0.1µH to 1.0mH

Operating Temp. -40°C to +85°C

Tinned Leads with Leaded Solder is Available

(note 4)

ELECTRICAL SPECIFICATIONS AT 25ºC

PART NO.

DR349-2-101

DR349-2-121

DR349-2-151

DR349-2-181

DR349-2-221

DR349-2-271

DR349-2-331

DR349-2-391

DR349-2-471

DR349-2-561

DR349-2-681

DR349-2-821

DR349-2-102

DR349-2-122

DR349-2-152

DR349-2-182

DR349-2-222

DR349-2-272

DR349-2-332

DR349-2-392

DR349-2-472

DR349-2-562

DR349-2-682

DR349-2-822

DR349-2-103

DR349-2-123

DR349-2-153

DR349-2-183

DR349-2-223

DR349-2-273

DR349-2-333

DR349-2-393

DR349-2-473

DR349-2-563

DR349-2-683

DR349-2-823

DR349-2-104

INDUCTANCE (µH)

@25.2MHz

0.10±10%

@25.2MHz

0.12±10%

@25.2MHz

0.15±10%

@25.2MHz

0.18±10%

@25.2MHz

0.22±10%

@25.2MHz

0.27±10%

@25.2MHz

0.33±10%

@25.2MHz

0.39±10%

@25.2MHz

0.47±10%

@25.2MHz

0.56±10%

@25.2MHz

0.68±10%

@25.2MHz

0.82±10%

@7.96MHz

1.0±5%

@7.96MHz

1.2±5%

@7.96MHz

1.5±5%

@7.96MHz

1.8±5%

@7.96MHz

2.2±5%

@7.96MHz

2.7±5%

@7.96MHz

3.3±5%

@7.96MHz

3.9±5%

@7.96MHz

4.7±5%

@7.96MHz

5.6±5%

@7.96MHz

6.8±5%

@7.96MHz

8.2±5%

@2.52MHz

10±5%

@2.52MHz

12±5%

@2.52MHz

15±5%

@2.52MHz

18±5%

@2.52MHz

22±5%

@2.52MHz

27±5%

@2.52MHz

33±5%

@2.52MHz

39±5%

@2.52MHz

47±5%

@2.52MHz

56±5%

@2.52MHz

68±5%

@2.52MHz

82±5%

@0.796MHz

100±5%

DCR (Ω) MAX.

0.18

0.20

0.22

0.24

0.25

0.26

0.28

0.30

0.32

0.36

0.40

0.45

0.50

0.55

0.60

0.65

0.70

0.75

0.80

0.90

1.0

1.1

1.2

1.4

1.5

2.0

2.5

2.8

3.2

3.6

4.0

4.5

5.0

5.5

6.0

7.0

8.0

MAX. RATED CURRENT (A)

0.800

0.770

0.730

0.700

0.665

0.635

0.605

0.575

0.545

0.520

0.500

0.475

0.450

0.430

0.410

0.390

0.380

0.370

0.355

0.330

0.315

0.300

0.285

0.270

0.250

0.225

0.200

0.190

0.180

0.170

0.160

0.150

0.140

0.135

0.130

0.120

0.110

DATATRONIC

28151 Highway 74, Romoland, CA 92585

Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701

Email: ddisales@datatronics.com

499 King’s Road, Hong KongTel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290

All specifications are subject to change without notice.
