TERMINATIONS
Type N, DC - 1
2.4 GHz, 10 Watts
SPECIFICATIONS:
Models: 3093F, 3093M, 3093MC, 3093FC
Electrical:
Frequency Range
VSWR
DC - 1 GHz
1 - 4 GHz
4 - 8 GHz
8 - 1 GHz
2.4
Impedance
Input Power
Peak Power
DC - 1 GHz
2.4
1. 0:1 Max.
1
1. 5:1 Max.
1
1.20:1 Max.
1.25:1 Max.
50 Ohms
10 Watts Avg. @ +25°C
Derated Linearly to 2 Watts @ +1
o
C
25
5 kW Max.
(5uSec Pulse, .05% Duty Cycle)
Mechanical:
Type N Connectors
Mates with MIL
-STD-348
Ø.13[3.3]
Thru
3.5 [89] Long
Bead Chain
Nickel Plated Brass
Anodized Aluminum
Gold Plated Beryllium Copper
Passivated Stainless Steel
Housing
Conductors
Bead Chain
CHAIN DETAIL
Model Number:
3093M
Type N Male Connector
Model Number:
3093F
Type N Female Connector
2.64 [67.1]
Max.
2.64[67.1]
Max.
Ø.77[19.6]
Max.
Ø.77[19.6]
Max.
HOW TO ORDER:
Model Number:
Ordering Examples:
3093XY
Style
= No Chain
C = Chain
Connector Configuration
M = Male
F = Female
Model Number:
3093MC
DC - 1 GHz; Type N Male; Chain Included
2.4
Model Number:
3093F
DC - 1 GHz; Type N Female; No Chain
2.4
Model Number:
3093M
DC - 1 GHz; Type N Male; No Chain
2.4
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design, specifications are subject to change without notice. Contact factory for technical
specifications before purchasing and/or use.
3093: REV B
Aeroflex / Inmet, Inc.
300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex.com/inmet
