SMD INDUCTOR DR336 SERIES
Features
Low Profile Surface Mount Design
Flat Top for Pick and Place
Inductance Range from 10µH to 1000µH
Operating Temp. -20°C to +80°C
Tinned Leads with Leaded Solder is Available
(note 4)
ELECTRICAL SPECIFICATIONS AT 25ºC
PART No.
DR336-103
DR336-123
DR336-153
DR336-183
DR336-223
DR336-273
DR336-333
DR336-393
DR336-473
DR336-563
DR336-683
DR336-823
DR336-104
DR336-124
DR336-154
DR336-184
DR336-224
DR336-274
DR336-334
INDUCTANCE (µH)
10
±
20%
12
±
20%
15
±
20%
18
±
20%
22
±
20%
27
±
20%
33
±
20%
39
±
20%
47
±
20%
56
±
20%
68
±
10%
82
±
10%
100
±
10%
120
±
10%
150
±
10%
180
±
10%
220
±
10%
270
±
10%
330
±
10%
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 2.52MHz
@ 1kHz
@ 1kHz
@ 1kHz
@ 1kHz
@ 1kHz
@ 1kHz
@ 1kHz
DCR
(Ω) Max.
0.08
0.09
0.10
0.11
0.13
0.17
0.18
0.22
0.25
0.28
0.33
0.45
0.48
0.54
0.75
1.02
1.20
1.31
1.50
RATED CURRENT
(A) Max.
1.44
1.39
1.24
1.12
1.07
0.94
0.85
0.74
0.68
0.64
0.59
0.54
0.51
0.49
0.40
0.36
0.31
0.29
0.28
MECHANICAL OUTLINES
7.80±0.3
[0.307]
8.00
[0.315]
3.50
[0.138]
2.00
[0.078]
1
7.50
[0.295]
7.00±0.3
[0.276]
XXX
2
TOP VIEW
SIDE VIEW
BOTTOM VIEW
PCB SOLDER PAD LAYOUT (REF.)
SCHEMATIC
NOTES:
1. All dimensions are shown in millimeters “mm” [inches “in”].
2. General tolerance
±0.25mm
[0.010 IN.], unless otherwise specified.
3. Tape and reel quantity, 1000 pcs/reel.
4. For non-RoHS parts, replace DR prefix with 42- (e.g. DR336 becomes 42-336).
5. Terminal finish is compliant to RoHS requirements. Solder in accordance with J-STD-020C.
