mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
Type
with wire protection
59
105
with wire protection
wire entry 45°
Electrical Data
Voltage
Current
Wire range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
300 V
10 A
16 - 22 AWG
### (see note)
3 lbs. - in
.9 mm
1.2 mm
5 mm
Electrical Data
Voltage
Current
Wire Range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
300 V
10 A
16 - 22 AWG
### (see note)
3 lbs. - in
.85 mm
1.2 mm
5 mm
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, tin over nickel plating
tin bronze, tin plated
M2, steel
nickel over copper plating
optional: brass, nickel plated
- consult factory
2 to 16
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, tin over nickel plating
tin bronze, tin plated
M2, steel
nickel over copper plating
optional: brass, nickel plated
- consult factory
2 to 16
Color
Terminal
Wire protector
Screw
Color
Terminal
Wire protector
Screw
Pole sizes
Pole sizes
Additional material data - pages DA-3 to DA-5
Additional material data - pages DA-3 to DA-5
Dimensions (mm)
Dimensions (mm)
L = (circuits - 1) x centerline + 3.5
L = (circuits - 1) x centerline + 3.5
Note for wire range
Additional wire sizes and/or
combinations of same size
wires as follows:
Part Numbers
Type 59
Complete the part number
by adding the pole size.
centerline 3.5 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
Type 105
Complete the part number
by adding the pole size.
centerline 3.5 mm
Part No.
310591
Part No.
311051
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
Type 59 and Type 105
###
2 No. 22-20 AWG
(Field-wiring);
2 No. 30-20 AWG or
1 No. 30-18 AWG
(Factory-wiring)
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
DA-7
