DR217-4 SERIES RADIAL LEADED INDUCTORS
Features
Designed for EMI Filters & Switching Power Supplies
Inductance Range from 2.2µH to 1500µH
Operating Temp. -20°C to +80°C
Tinned Leads with Leaded Solder is Available
(note 5)
ELECTRICAL SPECIFICATIONS AT 25ºC
Part Number
Inductance
(uH) @1kHz
Q
Min.
Q Test
Freq.
SRF (MHz)
Ref.
DCR (Ohm)
Max.
Rated
Current
(A)
Max. I sat
5.5
3.8
3.7
2.8
2.5
2
1.6
1.3
1.1
0.91
0.75
0.61
0.5
0.41
0.34
0.28
0.23
0.18
Rated
Current (A)
Max. I rms
4
3.4
3
2.6
2.2
1.9
1.5
1.2
1
0.97
0.81
0.61
0.53
0.44
0.39
0.32
0.26
0.21
DR217-4-222
DR217-4-332
DR217-4-472
DR217-4-682
DR217-4-103
DR217-4-153
DR217-4-223
DR217-4-333
DR217-4-473
DR217-4-683
DR217-4-104
DR217-4-154
DR217-4-224
DR217-4-334
DR217-4-474
DR217-4-684
DR217-4-105
DR217-4-155
2.2 ± 20%
3.3 ± 20%
4.7 ± 20%
6.8 ± 20%
10 ± 10%
15 ± 10%
22 ± 10%
33 ± 10%
47 ± 10%
68 ± 10%
100 ± 10%
150 ± 10%
220 ± 10%
330 ± 10%
470 ± 10%
680 ± 10%
1000 ± 10%
1500 ± 10%
10
10
10
10
20
20
20
20
20
20
15
15
15
15
10
10
20
30
7.96MHz
7.96MHz
7.96MHz
7.96MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
252kHz
252kHz
60
38
30
24
19
15
12
10
8.2
6.6
5.4
4.3
3.5
2.8
2.3
1.9
1.5
1.2
.196 ±.039
5,00 ±1,00
0.011
0.013
0.017
0.023
0.031
0.042
0.07
0.092
0.13
0.16
0.23
0.4
0.53
0.78
1
1.5
2.2
3.5
MECHANICAL SPECIFICATIONS
.118 MAX.
3,00
1
XXX
Ø .374 MAX.
9,50
1
.413 MAX.
10,50
.590 MIN.
15,00
2
Ø .025
TYP
0,65
2
SCHEMATIC
NOTES:
1. Dimensions are shown in inches/millimeters
2. Unless otherwise specified, tolerance = Inches: ±0.012
= Millimeters: ±0,30
3. Isat based on the inductance being 90% of its initial value
4. Irms based on a temperature rise of 20°C
5. For non-RoHS parts replace DR prefix with 42- (e.g. DR217-4 becomes 42-217-4)
6. Terminal finish is compliant to RoHS requirements
