mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
Type
with wire protection
modular
55
Non Modular Type
similar to
Type 55
Type 01
similar to
Type 81
Type 03
Page DA-12
Page DA-11
81
with wire protection
modular
Electrical Data
Voltage
Current
Wire Range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
300 V
15 A
14 - 22 AWG
#, ++ (see note)
7 lbs. - in
.9 mm
1.3 mm
6 mm
Electrical Data
Voltage
Current
Wire Range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
300 V
20 A
12 - 22 AWG
#, + (see note)
7 lbs. - in
1 mm
1.3 mm
8 mm
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
gray
brass, tin over nickel plating
tin bronze, tin plated
M3, steel,
nickel over copper plating
optional: brass, nickel plated
- consult factory
2 to 4
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, tin over nickel plating
tin bronze, tin plated
M3, steel
nickel over copper plating
optional: stainless steel
- consult factory
2 to 4
Color
Terminal
Wire protector
Screw
Color
Terminal
Wire protector
Screw
Pole sizes
Pole sizes
Additional material data - pages DA-3 to DA-5
Additional material data - pages DA-3 to DA-5
Dimensions (mm)
Dimensions (mm)
Note for wire range
Additional wire sizes and/or
combinations of same size
wires as follows:
Type 55
#
++
1 No. 30 AWG
(Factory-wiring);
2 No. 22-18 AWG
(Field-wiring);
2 No. 30-18 AWG
(Factory-wiring)
1 No. 30 AWG
(Field-wiring);
2 No. 22-16 AWG
(Field-wiring);
2 No. 30-16 AWG
(Factory-wiring)
L = (circuits - 1) x centerline + 5
L = (circuits - 1) x centerline + 5
Part Numbers
Type 55
Complete the part number
by adding the pole size.
centerline 5 mm
Part Numbers
02 03 04
Type 81
Complete the part number
by adding the pole size.
centerline 5 mm
02 03 04
Type 81
#
+
Part No.
310551
Part No.
310811
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
DA-15
