mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
229
Additional Centerline
Type 229
Type 229
Type 230
Type 230
Voltage
square pins
1 mm square
open end
Type
230
300 V - centerline 5.08 mm
600 V - centerline 10.16 mm
15 A
1 mm - mating
1 mm - solder
1.5 mm
3.45 mm
Voltage
square pins
1 mm square
closed end
Electrical Data
Electrical Data
300 V - centerline 5.08 mm
600 V - centerline 10.16 mm
15 A
1 mm - mating
1 mm - solder
1.5 mm
3.45 mm
Current
Square pins
PCB hole diameter
Solder pin length
Current
Square pins
PCB hole diameter
Solder pin length
Terminal block that mates with
Type 229
and
Type 230
Type 249
Type 213
Type 214
Page DB-16
Page DB-15
Page DB-15
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
copper alloy,
silver over nickel plating
optional: gold plating
- consult factory
2 to 24 - centerline 5.08 mm
2 to 12 - centerline 10.16 mm
Additional data - page H-3
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
copper alloy,
silver over nickel plating
optional: gold plating
- consult factory
2 to 24 - centerline 5.08 mm
2 to 12 - centerline 10.16 mm
Additional data - page H-3
Accessories
for
Type 229
and
Type 230
Coding set 720254-01-6
Coding set 720254-02-5
Page J-10
Color
Pin
Color
Pin
Pole sizes
Pole sizes
Dimensions (mm)
Dimensions (mm)
L = (circuits - 1) x centerline + 5.08
L = (circuits - 1) x centerline + 6.28
Part Numbers
Type 229
Complete the part number
by adding the pole size.
centerline 5.08 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
02 03 04 05 06 07 08
09 10 11 12
Part No.
312291
Type 229
centerline 10.16 mm
Part No.
312301
Type 230
centerline 10.16 mm
Part No.
312292
Part No.
312302
02 03 04 05 06 07 08
09 10 11 12
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
H-27
H
Type 230
Complete the part number
by adding the pole size.
centerline 5.08 mm
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
