mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
265
Terminal block that mates with
Type 265
and
Type 266
Type 262
Page DB-17
square pins
1 mm square
open end
Type
266
600 V
15 A
1 mm - mating
1 mm - solder
1.5 mm
3.45 mm
square pins
1 mm square
closed end
Electrical Data
Voltage
Current
Square pins
PCB hole diameter
Solder pin length
Electrical Data
Voltage
Current
Square pins
PCB hole diameter
Solder pin length
600 V
15 A
1 mm - mating
1 mm - solder
1.5 mm
3.45 mm
Accessories
for
Type 265
and
Type 266
Coding Set 720254-01-6
Coding Set 720254-02-5
Page J-10
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
tin plating over nickel plating
2 to 12
Additional data - page H-3
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
tin plating over nickel plating
2 to 12
Additional data - page H-3
Color
Pin
Pole sizes
Color
Pin
Pole sizes
Dimensions (mm)
Dimensions (mm)
L = (circuits - 1) x centerline + 5.82
L = (circuits - 1) x centerline + 7.62
Part Numbers
Type 265
Complete the part number
by adding the pole size.
centerline 7.62 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12
Part No.
312651
Part No.
312661
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
H-33
H
Type 266
Complete the part number
by adding the pole size.
centerline 7.62 mm
02 03 04 05 06 07 08
09 10 11 12
