89
Headers
to
Type 007
and
Type 077
Type 017
Type 027
Type 039
Type 041
Type 417
page 126
page 126
page 136
page 129
page 128
Type 007
Screw type terminal block, pluggable, centerline 5 mm /
0.197 inches, wire entry perpendicular to plug
direction, wire protector, female contact
Type 077
Screw type terminal block, pluggable, centerline 5 mm /
0.197 inches, wire entry perpendicular to plug
direction, wire protector, modular, female contact
A
Technical Data
V / A / AWG
300 / 15 / 22 - 12
Technical Data
V / A / AWG
300 / 15 / 22 - 14
0.33 - 2.5 mm² 125 V / 2.5 kV / 10 A
0.33 - 2.5 mm² 125 V / 2.5 kV / 10 A
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 2.3 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
160
400
400
Rated test voltage
2.5
4
2.5
Protection category according
IP00
to IEC 529
Tightening torque UL
4.4 lb-in max.
Min. insul. strip length
6 mm
Pole size
2-3
Color
black
Accessories
for
Type 007
Coding pin
710121 short
710122 long
page 202
Coding set
716846
page 203
Latching flange
710084 right
710085 left
page 199
for
Type 077
Coding pin
710121 short
710122 long
page 202
Coding set
716846
page 203
Mounting flange
750150 right
750151 left
page 200
Insulation co-ordination according to EN 60664-1
Clearance and creepage distances min. 2.3 mm
Insulating material class
CTI 600
Overvoltage category
III
III
II
Pollution degree
3
2
2
Rated voltage
160
400
400
Rated test voltage
2.5
4
2.5
Protection category according
to IEC 529
IP20
Tightening torque UL
4.4 lb-in max.
Min. insul. strip length
6 mm
Pole size
2 - 24
Color
black
Dimensions in mm
1 mm = 0.0394 in.
Dimensions in mm
1 mm = 0.0394 in.
Note for wire range
Additional wire sizes and/or
combinations of same size
wires as follows:
Type 07
and
Type 77
#(1) Wire range extended
to No. 30 AWG for
factory-wiring.
+
Two same size wires
No. 22 - 16 AWG Cu
Sol/Str for field-wiring;
No. 30 - 16 AWG Cu
Sol/Str factory-wiring.
L = (pole size - 1) x centerline + 5 mm / 0.197 inches
L = (pole size - 1) x centerline + 5 mm / 0.197 inches
Part numbers (P/N)
Type 007
centerline 5 mm / 0.197 inches
(information: page 56)
Complete the part number by
adding the pole size.
Part numbers (P/N)
Type 077
(information: page 56)
Complete the part number by
adding the pole size.
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
centerline 5 mm / 0.197 inches
02 03
P/N
310071
Type 007
centerline 10 mm / 0.394 inches
P/N
310771
02 03 04 05 06 07 08
09 10 11 12
P/N
310072
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
Standard pole sizes
Available on demand. Minimum order quantity 5000
pieces per item.
