THIS COPY IS PROVIDED ON A RESTRICTED BASIS AND IS NOT TO BE USED IN ANY WAY DETRIMENTAL TO THE INTERESTS OF PANCON.
.06
.32
8.2
1.52
"G"
.35
8.9
"E"
"D"
.100
2.54
CIRCUIT #1
.100
2.54
INDICATES
CIRCUIT #1
.040 .003 DIA
[1.02 0.08]
.11 DIA
[2.8]
55
"Z"
.236
6.0
.66
16.7
"Y"
"W"
"X"
.02
"G"
0.5
.100
2.54
.025 SQ. PIN
[6.35] SQ. PIN
X
Pb
TM
RoHS
Compliant
Bolingbrook, Illinois
LAT-CON
050 SERIES HEADER
STRAIGHT SOLDER TAIL
UNLESS OTHERWISE SPECIFIED,
DIMENSIONAL TOLERANCES ARE:
UNLESS OTHERWISE SPEC-
IFIED, ALL DIMENSIONS
ARE GIVEN IN INCHES.
THIRD ANGLE PROJECTION.
S C A L E
(.X)
(.XX)
D R A W N
(.XXX)
ANGLES
.02(.5)
B Y
MAT'L
.010(0.25)
4
RWC
12
6/6
/11
2:1
N O.
SC
BY
CHK
ADDED PDNI PLATING
DESCRIPTION
2330
CN - R
CUST
SUP
D A T E
5-3-88
C H K'D
SEE NOTES
D R A W I N G
DWG.
REV DATE
KGI
KA-10240
SHT 1 OF 2
A
SIZE
THIS COPY IS PROVIDED ON A RESTRICTED BASIS AND IS NOT TO BE USED IN ANY WAY DETRIMENTAL TO THE INTERESTS OF PANCON.
HEADER PART NUMBERING SYSTEM
NO.OF CIRCUITS
NUMBER
OF
CIRCUITS
10
14
16
20
26
34
40
44
50
60
64
"D"
IN
1.28
1.48
1.58
1.77
2.07
2.47
2.77
2.96
3.26
3.76
3.96
[mm]
[32.5]
[37.6]
[40.0]
[45.0]
[52.6]
[62.7]
[70.4]
[75.2]
[82.8]
[95.5]
[100.6]
HEADER DIMENSIONS
"E"
IN
.40
.60
.70
.90
1.20
1.60
1.90
2.10
2.40
2.90
3.10
[mm]
[10.2]
[15.2]
[17.8]
[22.9]
[30.5]
[40.6]
[48.3]
[53.3]
[61.0]
[73.7]
[78.7]
IN
1.10
1.30
1.40
1.60
1.90
2.30
2.60
2.80
3.10
3.60
3.80
"G"
[mm]
[27.9]
[33.0]
[35.6]
[40.6]
[48.3]
[58.4]
[66.0]
[71.1]
[78.7]
[91.4]
[96.5]
WEIGHT
PER 100 PCS.
LBS GRAMS
.75
.89
.95
1.09
1.28
1.53
1.78
1.92
2.17
2.25
2.66
342
404
431
496
584
696
808
871
985
1143
1206
SERIES
PIN TYPE
0=ANGLED
1=STRAIGHT
050-034-1
- STANDARD HOUSING
H HIGH TEMP. HSG.
5
2
H
A
SELECTIVE PLATING
1= 200m" BRIGHT TIN
3= 30m" GOLD OR
GOLD FLASH OVER 24m" PDNI
5= 15m" GOLD OR
GOLD FLASH OVER 12m" PDNI
PIN LENGTH - "X"
2 = .177"
3 = .114"
DESIGNATION FOR 10
CIRCUIT MILITARY
STYLE KEYING ONLY...
LEAVE BLANK FOR OTHER
CIRCUIT SIZES AND
CENTER OR NON-POLARIZED
10 CIRCUIT HEADERS.
WEIGHT
DIMENSIONS
PER 20 LATCHES
"W"
"Y"
"Z"
LBS
GRAMS
IN [mm] IN
[mm] IN
[mm]
9.1
.20 [5.2] .94 [24.0] .42 [10.7] .020
SHORT LATCH (A)
9.8
.24 [6.1] 1.04 [26.5] .57 [14.5] .022
LONG LATCH (B)
LATCH/EJECTOR
LENGTH
NOTES:
1. HOUSING MATERIAL: STANDARD; GF PBT 94V0 LIGHT GRAY
HIGH TEMP: GF HT NYLON 94V0, BLACK
2. POST MATERIAL: BRASS ALLOY; W/GOLD OR PALLADIUM NICKEL
W/GOLD FLASH IN MATING AREA AND TIN PLATING OVER NICKEL
ON SOLDER TAILS
BRIGHT TIN OVER NI OVERALL FOR -1- PARTS.
3. ALL DIMENSIONS SHOWN IN INCHES AND mm.
LATCH TYPE
A = SHORT
B = LONG
LEAVE BLANK
FOR NONE
U.L. RECOGNIZED: FILE E73711
X
Pb
TM
RoHS
Compliant
Bolingbrook, Illinois
LAT-CON
050 SERIES HEADER
STRAIGHT SOLDER TAIL
UNLESS OTHERWISE SPECIFIED,
DIMENSIONAL TOLERANCES ARE:
UNLESS OTHERWISE SPEC-
IFIED, ALL DIMENSIONS
ARE GIVEN IN INCHES.
THIRD ANGLE PROJECTION.
S C A L E
(.X)
(.XX)
D R A W N
(.XXX)
ANGLES
.02(.5)
B Y
MAT'L
.010(0.25)
4
RWC
12
REV DATE
BY
CHK
2:1
N O.
SEE SHEET 1
DESCRIPTION
CN - R
CUST
SUP
D A T E
5-3-88
C H K'D
SEE NOTES
D R A W I N G
DWG.
KGI
KA-10240
SHT 2 OF 2
A
SIZE
