MC68HC908JK1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> The embedded processor and controller> MC68HC908JK1

MC68HC908JK1: Description8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20; Categorysemiconductor The embedded processor and controller; File Size550KB，210 Pages; ManufacturerMotorola ( NXP ); Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

MC68HC908JK1 Overview

8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20

MC68HC908JK1 Parametric

Parameter Name	Attribute value
Number of functions	1
Number of terminals	20
Maximum operating temperature	85 Cel
Minimum operating temperature	-40 Cel
Maximum supply/operating voltage	3.3 V
Minimum supply/operating voltage	2.7 V
Rated supply voltage	3 V
External data bus width	0.0
Number of input and output buses	15
Line speed	4 MHz
Processing package description	PLASTIC, DIP-20
state	TRANSFERRED
Craftsmanship	HCMOS
packaging shape	RECTANGULAR
Package Size	IN-LINE
Terminal form	THROUGH-HOLE
Terminal spacing	2.54 mm
Terminal location	DUAL
Packaging Materials	PLASTIC/EPOXY
Temperature level	INDUSTRIAL
ADC channel	Yes
Address bus width	0.0
Number of digits	8
Maximum FCLK clock frequency	16 MHz
Microprocessor type	MICROCONTROLLER
PWM channel	Yes
ROM programming	FLASH

Preview

Download Datasheet

View All

MC68H

MC68HC908

MC68HRC908

MC68HC908

MC68HRC908

MC68HC908

MC68HRC908

TECHNICAL

HCMOS Microcontrolle

MC68HC908JK1 Related Products

	MC68HC908JK1	MC68HC908JK1CP	MC68HC908JK3	MC68HC908JL3	MC68HRC908JK1CDW	MC68HRC908JK1CP	MC68HRC908JK3	MC68HRC908JK3CP	MC68HRC908JL3	MC68HRC908JK1
Description	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20	8-BIT, FLASH, 4 MHz, MICROCONTROLLER, PDIP20
Number of terminals	20	20	20	20	20	20	20	20	20	20
Maximum operating temperature	85 Cel	85 °C	85 Cel	85 Cel	85 °C	85 °C	85 Cel	85 °C	85 Cel	85 Cel
Minimum operating temperature	-40 Cel	-40 °C	-40 Cel	-40 Cel	-40 °C	-40 °C	-40 Cel	-40 °C	-40 Cel	-40 Cel
External data bus width	0.0	-	0.0	0.0	-	-	0.0	-	0.0	0.0
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	GULL WING	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Address bus width	0.0	-	0.0	0.0	-	-	0.0	-	0.0	0.0
PWM channel	Yes	YES	Yes	Yes	YES	YES	Yes	YES	Yes	Yes
Number of functions	1	-	1	1	-	-	1	-	1	1
Maximum supply/operating voltage	3.3 V	-	3.3 V	3.3 V	-	-	3.3 V	-	3.3 V	3.3 V
Minimum supply/operating voltage	2.7 V	-	2.7 V	2.7 V	-	-	2.7 V	-	2.7 V	2.7 V
Rated supply voltage	3 V	-	3 V	3 V	-	-	3 V	-	3 V	3 V
Number of input and output buses	15	-	15	15	-	-	15	-	15	15
Line speed	4 MHz	-	4 MHz	4 MHz	-	-	4 MHz	-	4 MHz	4 MHz
Processing package description	PLASTIC, DIP-20	-	PLASTIC, DIP-20	PLASTIC, DIP-20	-	-	PLASTIC, DIP-20	-	PLASTIC, DIP-20	PLASTIC, DIP-20
state	TRANSFERRED	-	TRANSFERRED	TRANSFERRED	-	-	TRANSFERRED	-	TRANSFERRED	TRANSFERRED
Craftsmanship	HCMOS	-	HCMOS	HCMOS	-	-	HCMOS	-	HCMOS	HCMOS
packaging shape	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	-	-	RECTANGULAR	-	RECTANGULAR	RECTANGULAR
Package Size	IN-LINE	-	IN-LINE	IN-LINE	-	-	IN-LINE	-	IN-LINE	IN-LINE
Terminal spacing	2.54 mm	-	2.54 mm	2.54 mm	-	-	2.54 mm	-	2.54 mm	2.54 mm
Packaging Materials	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	-	-	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY
ADC channel	Yes	-	Yes	Yes	-	-	Yes	-	Yes	Yes
Number of digits	8	-	8	8	-	-	8	-	8	8
Maximum FCLK clock frequency	16 MHz	-	16 MHz	16 MHz	-	-	16 MHz	-	16 MHz	16 MHz
Microprocessor type	MICROCONTROLLER	-	MICROCONTROLLER	MICROCONTROLLER	-	-	MICROCONTROLLER	-	MICROCONTROLLER	MICROCONTROLLER
ROM programming	FLASH	-	FLASH	FLASH	-	-	FLASH	-	FLASH	FLASH
