B43464A5228M000 datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> B43464A5228M000

B43464A5228M000: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 450V, 2200uF, CHASSIS MOUNT, ROHS COMPLIANT; CategoryPassive components capacitor; File Size437KB，17 Pages; ManufacturerEPCOS (TDK)

Download Datasheet Parametric Compare View All

B43464A5228M000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	B43464A5228M000	-	-	View	Buy Now

B43464A5228M000 Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 450V, 2200uF, CHASSIS MOUNT, ROHS COMPLIANT

B43464A5228M000 Parametric

Parameter Name	Attribute value
Maker	EPCOS (TDK)
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
capacitance	2200 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	64.3 mm
dielectric materials	ALUMINUM (WET)
ESR	50 mΩ
leakage current	3.249363 mA
length	105.7 mm
Manufacturer's serial number	B43464
Installation features	CHASSIS MOUNT
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package shape	CYLINDRICAL PACKAGE
Package form	Screw Ends
method of packing	CARDBOARD
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	450 V
ripple current	8200 mA
series	B43464
surface mount	NO
Terminal pitch	28.5 mm
Terminal shape	BINDING POST
Base Number Matches	1

Preview

Download Datasheet

View All

Aluminum electrolytic capacitors

Capacitors with screw terminals

Series/Type:

Date:

B43464, B43484

February 2014

information contained therein without EPCOS' prior express consent is prohibited.

B43464A5228M000 Related Products

	B43464A5228M000	B43464A5108M000	B43464B9228M000	B43464A4828M000	B43464A5568M000	B43464A9129M000
Description	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 450V, 2200uF, CHASSIS MOUNT, ROHS COMPLIANT	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 450V, 1000uF, CHASSIS MOUNT, ROHS COMPLIANT	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 400V, 2200uF, CHASSIS MOUNT, ROHS COMPLIANT	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 350V, 8200uF, CHASSIS MOUNT, ROHS COMPLIANT	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 450V, 5600uF, CHASSIS MOUNT, ROHS COMPLIANT	CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 400V, 12000uF, CHASSIS MOUNT, ROHS COMPLIANT
Maker	EPCOS (TDK)	EPCOS (TDK)	EPCOS (TDK)	EPCOS (TDK)	EPCOS (TDK)	EPCOS (TDK)
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
capacitance	2200 µF	1000 µF	2200 µF	8200 µF	5600 µF	12000 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	64.3 mm	51.6 mm	64.3 mm	76.9 mm	76.9 mm	76.9 mm
dielectric materials	ALUMINUM (WET)	ALUMINUM (WET)	ALUMINUM (WET)	ALUMINUM (WET)	ALUMINUM (WET)	ALUMINUM (WET)
ESR	50 mΩ	110 mΩ	55 mΩ	16 mΩ	20 mΩ	10 mΩ
leakage current	3.249363 mA	1.664367 mA	2.940186 mA	8.023974 mA	7.184651 mA	12.421335 mA
length	105.7 mm	80.7 mm	80.7 mm	143.2 mm	143.2 mm	220.7 mm
Manufacturer's serial number	B43464	B43464	B43464	B43464	B43464	B43464
Installation features	CHASSIS MOUNT	CHASSIS MOUNT	CHASSIS MOUNT	CHASSIS MOUNT	CHASSIS MOUNT	CHASSIS MOUNT
negative tolerance	20%	20%	20%	20%	20%	20%
Number of terminals	2	2	2	2	2	2
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Package shape	CYLINDRICAL PACKAGE	CYLINDRICAL PACKAGE	CYLINDRICAL PACKAGE	CYLINDRICAL PACKAGE	CYLINDRICAL PACKAGE	CYLINDRICAL PACKAGE
Package form	Screw Ends	Screw Ends	Screw Ends	Screw Ends	Screw Ends	Screw Ends
method of packing	CARDBOARD	CARDBOARD	CARDBOARD	CARDBOARD	CARDBOARD	CARDBOARD
polarity	POLARIZED	POLARIZED	POLARIZED	POLARIZED	POLARIZED	POLARIZED
positive tolerance	20%	20%	20%	20%	20%	20%
Rated (DC) voltage (URdc)	450 V	450 V	400 V	350 V	450 V	400 V
ripple current	8200 mA	4700 mA	7500 mA	18400 mA	16200 mA	27800 mA
series	B43464	B43464	B43464	B43464	B43464	B43464
surface mount	NO	NO	NO	NO	NO	NO
Terminal pitch	28.5 mm	22.2 mm	28.5 mm	31.7 mm	31.7 mm	31.7 mm
Terminal shape	BINDING POST	BINDING POST	BINDING POST	BINDING POST	BINDING POST	BINDING POST
Base Number Matches	1	1	1	1	1	1
