D300RW
Single & Dual Output
3W SIP, Wide Input
DC/DC Converters
Electrical Specifications
Series
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
3W Output Power
•
2:1 Input Voltage Range
•
1,500 VDC Isolation
•
Short Circuit Protected
•
Miniature SIP Case
•
Single & Dual Outputs
•
1.0 MH MTBF
•
Industry Standard Pin-Out
Input
Parameter
Input Voltage Range
Short Circuit Input Power
Conditions
12 VDC Input
24 VDC Input
Min.
9.0
18.0
Typ.
12.0
24.0
1,500
Conditions
Min.
Typ.
±1.0
±1.0
Vin = Min to Max
Iout = 10% to 100%
Iout = 10% to 100%
120
±0.03
Continuous (Autorecovery)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Iout = 100%
Conditions
Ambient
200
Min.
-40
-50
Free Air Convection
RH, Non-condensing
95
%
Typ.
+25
Min.
1,500
1,000
80
500
Max.
+85
+125
Typ.
Max.
Units
VDC
MΩ
pF
kHz
Units
°C
°C
±0.2
±0.5
±0.5
50
Max.
±3.0
±2.0
±0.5
±0.75
±1.0
100
Max.
18.0
36.0
Units
VDC
mW
Units
%
%
%
%
%
mV P - P
%
%/°C
Output
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation , Single Output
Load Regulation , Dual Output
Ripple & Noise (20 MHz) (Note 1)
Output Power Protection
Temperature Coefficient
Output Short Circuit
General
RoHS Compliant
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Environmental
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T: (781) 344-8226
F: (781) 344-8481
E: sales@micropowerdirect.com
W: www.micropowerdirect.com
Physical
Case Size
Case Material
Weight
0.87 x 0.47 x 0.37 Inches (22.0 x 12.0 x 9.50 mm)
Non-Conductive Black Plastic (UL94-V0)
0.20 Oz (6.0g)
Conditions
MIL HDBK 217F, 25°C, Gnd Benign
Conditions
12 VDC Input
24 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
1.0
Min.
-0.7
-0.7
Typ.
Max.
22.0
40.0
300
1,800
Typ.
Max.
Units
MHours
Units
VDC
°C
mW
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Internal Power Dissipation
Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
Model Selection Guide
Model
Number
D301RW
D302RW
D303RW
D304RW
D305RW
D306RW
D307RW
D308RW
D311RW
D312RW
D313RW
D314RW
D315RW
D316RW
D317RW
D318RW
Input
Output
Efficiency
Voltage (VDC)
Current (mA)
Voltage Current
Current
(%, Typ)
Nominal
Range
Full-Load No-Load (VDC) (mA, Max) (mA, Min)
12
9.0 - 18.0
320
22
5.0
600.0
60.0
78
12
9.0 - 18.0
316
22
9.0
333.0
33.0
79
12
9.0 - 18.0
312
22
12.0
250.0
25.0
80
12
9.0 - 18.0
312
22
15.0
200.0
20.0
80
12
9.0 - 18.0
320
22
±5.0
±300.0
±30.0
78
12
9.0 - 18.0
316
22
±9.0
±167.0
±17.0
79
12
9.0 - 18.0
312
22
±12.0
±125.0
±13.0
80
12
9.0 - 18.0
312
22
±15.0
±100.0
±10.0
80
24
18.0 - 36.0
160
10
5.0
600.0
60.0
78
24
18.0 - 36.0
158
10
9.0
333.0
33.0
79
24
18.0 - 36.0
156
10
12.0
250.0
25.0
80
24
18.0 - 36.0
154
10
15.0
200.0
20.0
81
24
18.0 - 36.0
160
10
±5.0
±300.0
±30.0
78
24
18.0 - 36.0
158
10
±9.0
±167.0
±17.0
79
24
18.0 - 36.0
156
8
±12.0
±125.0
±13.0
80
24
18.0 - 36.0
154
8
±15.0
±100.0
±10.0
81
Fuse Rating
Slow-Blow
(mA)
700
700
700
700
700
700
700
700
350
350
350
350
350
350
350
350
Notes:
1. When measuring output ripple, it is recommended that an external ceramic capaci-
tor (approx. 1 µF to 10 µF) be placed from the +Vout pin to the -Vout pin for single
output units and from each output to common for dual output units.
2. These units should not be operated with a load under 10% of full load. Operation
at no-load may cause damage to the unit.
3. These converters are specified for operation without external components. However,
in some applications the addition of input/output capacitors will enhance stability and
reduce output ripple.
Output Capacitor
Recommended capaci-
Input
Vin Capacitor Vout 0 - 70ºC -40 - 85ºC
tor values are given in
(Electrolitic) (Tantalum)
the table at right. Using
12 VDC
100
µF
5 VDC
100
µF
47
µF
simple LC filter networks
100
µF
47
µF
on the input/output will 24 VDC 10 - 47
µF
9 VDC
provide further improve-
12 VDC
100
µF
47
µF
ment. This only requires
15 VDC
100
µF
47
µF
the addition of small
inductors to the input/output filter circuits. Recommended values are 4.7 µH to 120
µH for an input inductor and 2.2 µH to 10 µH for an output inductor.
Output ripple on single output units may
Output Voltage
be further enhanced by using the CS termi-
nal (single output units operated at 50%
5V
9V
12V
15V
load or below should use this function). A
CS
47
µF
- 100
µF
22
µF
- 47
µF
low ESR capacitor is connected between
the CS pin and the -Vout pin (the anode of the capacitor is connected to the -Vout
pin). Recommended capacitor values are given in the table above. If not used, the
CS pin should be left open.
4. Dual output units may be connected to provide a 10V, 18V, 24V or 30 VDC output.
To do this, connect the load across the +Vout and -Vout outputs and float the
output common.
Min
Max
5. The remote on/off control pin is referenced
On
<0.6 VDC to Open Circuit
to the -Vin pin (pin 1). Input current to the
pin should be between 5 - 10 mA with a
Off
2.7 VDC
15.0 VDC
maximum of 20 mA.
6. It is recommended that a fuse be used on the input of a power supply for protec-
tion. See the Model Selection table above for the correct rating.
Mechanical Dimensions
Mechanical Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.01 (±0.25)
Derating Curve
Capacitive Load
Output
5.0 VDC
9.0 VDC
12.0 VDC
15.0 VDC
±5.0 VDC
±9.0 VDC
±12.0 VDC
±15.0 VDC
Max Cap Load
2,200
µF
1,000
µF
820
µF
680
µF
±560
µF
±470
µF
±330
µF
±220
µF
Pin Connections
Pin Single
Dual
1
-Vin
-Vin
2
+Vin
+Vin
3
Remote ON/OFF
5
NF
NF
6 +Vout
+Vout
7
-Vout Common
8
CS
-Vout
NF = No Function
MicroPower Direct
www.micropowerdirect.com
•
292 Page Street Ste D Stoughton, MA 02072
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
