D200I
Series
High Isolation
Miniature, 2W SIP
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
2W Output Power
•
Miniature SIP Case
•
Single & Dual Outputs
•
3,000 VDC Isolation
•
>1.12 MHour MTBF
•
28 Standard Models
•
Industry Standard Pin-Out
Input
Parameter
Conditions
Min.
Typ.
5.0
12.0
24.0
48.0
20
Typ.
Max.
5.5
13.2
26.4
52.8
Units
Input Voltage Range
Input Filter
Reflected Ripple Current
5 VDC Input
4.5
12 VDC Input 10.8
24 VDC Input 21.6
48 VDC Input 43.2
Internal Capacitor
12
μH
Source Inductance
Conditions
Min.
VDC
mA P - P
Max.
Units
%
%
%
mV P - P
%
%/ºC
Output
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20 MHz)
Output Power Protection
Temperature Coefficient
Output Short Circuit
±3.0
Dual Output , Balanced Loads
±1.0
For Vin Change of 1%
±1.2
See Model Selection Guide
75
120
±0.02
Momentary (0.5 Sec.)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
3,000
1,000
60
80
Min.
Ambient
Case
-40
Typ.
+25
Max.
+85
+100
+125
95
Typ.
Max.
Units
VDC
MΩ
pF
kHz
Units
ºC
ºC
ºC
%
RoHS Compliant
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Conditions
-40
Free Air Convection
RH, Non-condensing
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
Physical
Case Size
(5V, 12V & 24V Input Models)
Case Size
(48V Input Models)
Case Material
Weight
0.76 x 0.24 x 0.39 Inches (19.5 x 6.0 x 10.0 mm)
0.76 x 0.28 x 0.39 Inches (19.5 x 7.2 x 10.0 mm)
Non-Conductive Black Plastic (UL94-V0)
0.08 Oz (2.3g)
Conditions
MIL HDBK 217F, 25ºC, Gnd Benign
Conditions
5 VDC Input
12 VDC Input
24 VDC Input
48 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
1.12
Min.
-0.7
-0.7
-0.7
-0.7
Typ.
Max.
7.0
15.0
28.0
54.0
260
650
Typ.
Max.
Units
MHours
Units
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
VDC
Lead Temperature
Internal Power Dissipation
ºC
mW
Caution:
Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
Model Selection Guide
Model
Number
D201I
D202I
D203I
D204I
D205I
D206I
D207I
D211I
D212I
D213I
D214I
D215I
D216I
D217I
D221I
D222I
D223I
D224I
D225I
D226I
D227I
D231I
D232I
D233I
D234I
D235I
D236I
D237I
Input
Output
Load
Voltage (VDC)
Current (mA)
Regulation
Voltage Current
Current
Nominal
Range
Full-Load No-Load (VDC) (mA, Max) (mA, Min) (%, Max)
5
4.5 - 5.5
367
30
3.3
400.0
10.0
20
5
4.5 - 5.5
512
30
5.0
400.0
8.0
10
5
4.5 - 5.5
500
30
12.0
165.0
3.5
10
5
4.5 - 5.5
500
30
15.0
133.0
2.7
10
5
4.5 - 5.5
555
30
±5.0
±200.0
±4.0
10
5
4.5 - 5.5
512
30
±12.0
±83.3
±1.7
10
5
4.5 - 5.5
500
30
±15.0
±66.6
±1.4
10
12
10.8 - 13.2
169
20
3.3
400.0
10.0
20
12
10.8 - 13.2
216
20
5.0
400.0
8.0
10
12
10.8 - 13.2
203
20
12.0
165.0
3.5
10
12
10.8 - 13.2
203
20
15.0
133.0
2.7
10
12
10.8 - 13.2
222
20
±5.0
±200.0
±4.0
10
12
10.8 - 13.2
203
20
±12.0
±83.3
±1.7
10
12
10.8 - 13.2
203
20
±15.0
±66.6
±1.4
10
24
21.6 - 26.4
76
10
3.3
400.0
10.0
20
24
21.6 - 26.4
105
10
5.0
400.0
8.0
10
24
21.6 - 26.4
102
10
12.0
165.0
3.5
10
24
21.6 - 26.4
101
10
15.0
133.0
2.7
10
24
21.6 - 26.4
111
10
±5.0
±200.0
±4.0
10
24
21.6 - 26.4
101
10
±12.0
±83.3
±1.7
10
24
21.6 - 26.4
101
10
±15.0
±66.6
±1.4
10
48
43.2 - 52.8
45
6
3.3
400.0
10.0
20
48
43.2 - 52.8
54
6
5.0
400.0
8.0
10
48
43.2 - 52.8
53
6
12.0
165.0
3.5
10
48
43.2 - 52.8
53
6
15.0
133.0
2.7
10
48
43.2 - 52.8
57
6
±5.0
±200.0
±4.0
10
48
43.2 - 52.8
52
6
±12.0
±83.3
±1.7
10
48
43.2 - 52.8
52
6
±15.0
±66.6
±1.4
10
Other input/output combinations are available
(i.e. 24.0 VDC). Contact the factory for details at:
sales@micropowerdirect.com
Efficiency
(%, Typ)
72
78
82
82
72
78
80
65
77
82
82
75
82
82
72
79
80
82
75
82
82
60
77
78
78
73
80
80
Fuse Rating
Slow-Blow
(mA)
1,000
1,000
1,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
500
200
200
200
200
200
200
200
100
100
100
100
100
100
100
Single
+Vin
-Vin
-Vout
No Pin
+Vout
Dual
+Vin
-Vin
-Vout
Common
+Vout
Capacitive Load
Single Output
(μF Max)
Dual Output
(μF Max)
±220
Pin Connections
Pin
1
2
5
6
7
470
Notes:
1. Output load regulation is specified for a load change of 20% to 100%.
2. These units do not require external components to operate, but the use of an input ca-
pacitor (10
μF)
may enhance performance in some applications. It is recommended that an
input capacitor of 4.7
uF
to 47
uF
(dependent upon the application) be used on 48V input
model.
An output capacitor (4.7
μF
to 220
μF
or ±4.7
μF
to ±100
μF)
may be used to reduce ripple.
To improve EMI performance, a simple filter network consisting of a 10
uF
to 100
uF
capaci-
tor and 12
uH
inductor should be effective.
3. These units will operate at no load without damage, but may not meet all specifications.
4. Dual output units may be connected to provide a 10V, 24V or 30 VDC output. To do this,
connect the load across the positive (+Vout) and negative (-Vout) outputs and float the
output common.
5. It is recommended that a fuse be used on the input of a power supply for
protection. See the table above for the correct rating.
Mechanical Dimensions
Derating Curve
MicroPower Direct
www.micropowerdirect.com
292 Page Street Ste D Stoughton, MA 02072
•
Notes:
•
All dimensions are typical in inches (mm)
dimensio
•
Tolerance x
x.xx =
±
0.01 (
±
0.25)
marked by a “dot” or indentation
•
Pin 1 is mar
on the side of the unit
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
E-Mail: sales@micropowerdirect.com
