D200
Series
Single & Dual Output
Miniature, 2W SIP
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
2W Output Power
•
Miniature SIP Case
•
Single & Dual Outputs
•
1,000 VDC Isolation
•
>1.12 MHour MTBF
•
28 Standard Models
•
Industry Standard Pin-Out
Input
Parameter
Input Voltage Range
Input Filter
Reflected Ripple Current
Min.
5 VDC Input
4.5
12 VDC Input 10.8
24 VDC Input 21.6
48 VDC Input 43.2
Internal Capacitor
12
µH
Source Inductance
Conditions
Min.
Conditions
Typ.
5.0
12.0
24.0
48.0
20
Max.
5.5
13.2
26.4
52.8
Units
VDC
mA P - P
Max.
Units
%
%
%
mV P - P
%
%/ºC
Output
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20 MHz)
Output Power Protection
Temperature Coefficient
Output Short Circuit
Typ.
±3.0
Dual Output , Balanced Loads
±1.0
For Vin Change of 1%
±1.2
See Model Selection Guide
75
120
Momentary (0.5 Sec.)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
1,000
1,000
Typ.
Max.
Units
VDC
M
pF
kHz
Units
ºC
ºC
ºC
%
±0.02
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
60
80
Min.
-40
Typ.
+25
Max.
+85
+100
+125
95
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Case Size
(5V, 12V & 24V Input Models)
Case Size
(48V Input Models)
Case Material
Weight
Reliability Specifications
Parameter
MTBF
Conditions
Ambient
Case
-40
Free Air Convection
RH, Non-condensing
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
0.76 x 0.24 x 0.39 Inches (19.5 x 6.0 x 10.0 mm)
0.76 x 0.28 x 0.39 Inches (19.5 x 7.2 x 10.0 mm)
Non-Conductive Black Plastic (UL94-V0)
0.08 Oz (2.3g)
Conditions
MIL HDBK 217F, 25ºC, Gnd Benign
Conditions
5 VDC Input
12 VDC Input
24 VDC Input
48 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
1.12
Min.
-0.7
-0.7
-0.7
-0.7
Typ.
Max.
Units
MHours
Units
Absolute Maximum Ratings
Parameter
Typ.
Max.
7.0
15.0
28.0
54.0
260
650
Input Voltage Surge (1 Sec)
VDC
Lead Temperature
Internal Power Dissipation
ºC
mW
Caution:
Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
www.micropowerdirect.com
Model Selection Guide
Model
Number
D201
D202
D203
D204
D205
D206
D207
D211
D212
D213
D214
D215
D216
D217
D221
D222
D223
D224
D225
D226
D227
D231
D232
D233
D234
D235
D236
D237
Input
Voltage (VDC)
Nominal
Range
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
48
43.2 - 52.8
48
43.2 - 52.8
48
43.2 - 52.8
48
43.2 - 52.8
48
43.2 - 52.8
48
43.2 - 52.8
48
43.2 - 52.8
www.micropowerdirect.com
Load
Regulation
(%, Max)
20
10
10
10
10
10
10
20
10
10
10
10
10
10
20
10
10
10
10
10
10
20
10
10
10
10
10
10
Efficiency
(%, Typ)
72
78
82
82
72
78
80
65
77
82
82
75
82
82
72
79
80
82
75
82
82
60
77
78
78
73
80
80
Fuse Rating
Slow-Blow
(mA)
1,000
1,000
1,000
1,000
1,000
1,000
1,000
500
500
500
500
500
500
500
200
200
200
200
200
200
200
100
100
100
100
100
100
100
Single
+Vin
-Vin
-Vout
No Pin
+Vout
Dual
+Vin
-Vin
-Vout
Common
+Vout
Output
Current (mA)
Voltage Current
Current
Full-Load No-Load (VDC) (mA, Max) (mA, Min)
367
30
3.3
400.0
10.0
512
30
5.0
400.0
8.0
500
30
12.0
165.0
3.5
500
30
15.0
133.0
2.7
555
30
±5.0
±200.0
±4.0
512
30
±12.0
±83.3
±1.7
500
30
±15.0
±66.6
±1.4
169
20
3.3
400.0
10.0
216
20
5.0
400.0
8.0
203
20
12.0
165.0
3.5
203
20
15.0
133.0
2.7
222
20
±5.0
±200.0
±4.0
203
20
±12.0
±83.3
±1.7
203
20
±15.0
±66.6
±1.4
76
10
3.3
400.0
10.0
105
10
5.0
400.0
8.0
102
10
12.0
165.0
3.5
101
10
15.0
133.0
2.7
111
10
±5.0
±200.0
±4.0
101
10
±12.0
±83.3
±1.7
101
10
±15.0
±66.6
±1.4
45
6
3.3
400.0
10.0
54
6
5.0
400.0
8.0
53
6
12.0
165.0
3.5
53
6
15.0
133.0
2.7
57
6
±5.0
±200.0
±4.0
52
6
±12.0
±83.3
±1.7
52
6
±15.0
±66.6
±1.4
Other input/output combinations are available
(i.e. 24.0 VDC). Contact the factory for details at:
sales@micropowerdirect.com
Capacitive Load
Single Output
(µF Max)
Dual Output
(µF Max)
±220
Pin Connections
Pin
1
2
4
5
6
470
Notes:
1. Output load regulation is specified for a load change of 20% to 100%.
2. These units do not require external components to operate, but the use of an input capacitor (10
µF)
may enhance performance in some applications. It is recommended that an input capacitor of 4.7
µF
to 47µF (dependent upon the application) be used on 48V input model.
An output capacitor (4.7
µF
to 220
µF
or ±4.7
µF
to ±100
µF)
may be used to reduce ripple. To improve
EMI performance, a simple filter network consisting of a 10
µF
to 100
µF
capacitor and 12
µH
inductor
should be effective.
3. These units will operate at no load without damage, but may not meet all specifications.
4. Dual output units may be connected to provide a 10V, 24V or 30 VDC output. To do this, connect the
load across the positive (+Vout) and negative (-Vout) outputs and float the output common.
5. It is recommended that a fuse be used on the input of a power supply for
protection. See the table above for the correct rating.
Mechanical Dimensions
Derating Curve
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx =
±
0.01 (
±
0.25)
•
Pin 1 is marked by a “dot” or indentation
on the side of the unit
FAX: (781) 344-8481
•
TEL: (781) 344-8226
•
E-Mail: sales@micropowerdirect.com
