D100VHI
Series
Miniature, 1W SIP
Ultra-High Isolation
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
1W Output Power
•
6.0 kVDC Isolation
•
Miniature SIP Case
•
Single & Dual Outputs
•
Miniature SIP Case
•
12 Standard Models
•
2.0 MH MTBF
•
Industry Standard Pin-Out
Input
Parameter
Input Voltage Range
Input Filter
Reverse Polarity Input Current
Conditions
5 VDC Input
12 VDC Input
Min.
4.5
10.8
Typ.
5.0
12.0
Max.
5.5
13.2
0.3
Conditions
Dual Output , Balanced Loads
For Vin Change of 1%
Min.
Typ.
±1.0
±0.1
±1.2
100
Over Line, Load & Temp.
120
±0.01
Momentary (0.5 Sec.)
Conditions
60 Seconds
Flash Tested For 1 Sec
500 VDC
100 kHz, 1V
50
Conditions
Ambient
Case
Min.
-40
-40
-40
Free Air Convection
RH, Non-condensing
95
%
Min.
6,000
6,600
10
15
80
Typ.
+25
20
100
Max.
+70
+90
+125
Typ.
Max.
Units
VDC
VDC
GΩ
pF
kHz
Units
°C
°C
°C
±0.02
Max.
±3.0
±1.0
±1.5
150
200
5
Units
VDC
Internal Capacitor
A
Units
%
%
%
mV P - P
mV P - P
mV rms
%
%/°C
Output
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation (Note 1)
Ripple & Noise (20 MHz) (Note 2)
Ripple & Noise (20 MHz)
Ripple & Noise (20 MHz)
Output Power Protection
Temperature Coefficient
Output Short Circuit
See Model Selection Guide
RoHS Compliant
General
Parameter
Isolation Voltage
Isolation Test Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T: (781) 344-8226
F: (781) 344-8481
E: sales@micropowerdirect.com
W: www.micropowerdirect.com
Cooling
Humidity
Physical
Case Size
Case Material
Weight
0.87 x 0.49 x 0.30 Inches (22.0 x 12.5 x 7.5 mm)
Non-Conductive Black Plastic (UL94-V0)
0.13 Oz (3.9g)
Conditions
MIL HDBK 217F, 25°C, Gnd Benign
Conditions
5 VDC Input
12 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
2.0
Min.
-0.7
-0.7
Typ.
Max.
9.0
18.0
260
650
Typ.
Max.
Units
MHours
Units
VDC
°C
mW
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Internal Power Dissipation
Caution:
Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
Model Selection Guide
Input
Model
Number
D101VHI
D102VHI
D103VHI
D104VHI
D105VHI
D106VHI
D111VHI
D112VHI
D113VHI
D114VHI
D115VHI
D116VHI
Voltage (VDC)
Nominal
5
5
5
5
5
5
12
12
12
12
12
12
Range
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
4.5 - 5.5
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
10.8 - 13.2
Load
Voltage
Current
Current Regulation
Full-Load No-Load (VDC) (mA, Max) (mA, Min) (%, Max)
Current (mA)
303
291
295
303
267
287
126
121
123
126
108
117
55
55
55
55
55
55
30
30
30
30
30
30
5.0
12.0
15.0
±5.0
±12.0
±15.0
5.0
12.0
15.0
±5.0
±12.0
±15.0
200.0
80.0
65.0
±100.0
±40.0
±35.0
200.0
80.0
65.0
±100.0
±40.0
±35.0
4.0
2.0
1.0
±2.0
±1.0
±1.0
4.0
2.0
1.0
±2.0
±1.0
±1.0
10
8
8
10
8
8
10
8
8
10
8
8
Output
Efficiency
(%, Typ)
66
66
66
66
72
73
66
66
66
66
74
75
Fuse Rating
Slow-Blow
(mA)
500
500
500
500
500
500
200
200
200
200
200
200
Notes:
1. Output load regulation is specified for a load change of 20%
to 100%.
2. When measuring output ripple, it is recomended that an exter-
nal 0.33
µF
ceramic capacitor be placed from the +Vout pin to
the -Vout pin for single output units and from each output to
common for dual output units.
3. Operation at no-load will not damage these units. However,
they may not meet all specifications.
4. Dual output units may be connected to provide a 10 VDC, 24
VDC or 30 VDC output. To do this, connect the load across the
positive (+Vout) and negative (-Vout) outputs and float the
output common.
5. It is recommended that a fuse be used on the input of a power
supply for protection. See the table above for the correct rat-
ing.
Derating Curve
Mechanical Dimensions
Pin Connections
Pin
1
2
5
6
7
Single
+Vin
-Vin
-Vout
No Pin
+Vout
Dual
+Vin
-Vin
-Vout
Common
+Vout
NC: No Connection
Capacitive Load
Single Output
µF
Max
680
Dual Output
µF
Max
±220
Mechanical Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.01 (±0.25)
MicroPower Direct
www.micropowerdirect.com
•
292 Page Street Ste D Stoughton, MA 02072
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
