EKV
www.vishay.com
Vishay Roederstein
Aluminum Capacitors
Radial Style
FEATURES
• Polarized aluminum electrolytic capacitor
• High ripple current
• High reliability
• High load life up to 10 000 h
• Temperature range up to 105 °C
• Compliant to RoHS Directive 2002/95/EC
APPLICATIONS
• For electronic lighting ballast
• Power supply
QUICK REFERENCE DATA
DESCRIPTION
Nominal case size (Ø D x L)
Rated capacitance range C
R
Capacitance tolerance
Rated voltage range
Category temperature range
Load life
Based on sectional specification
Climatic category IEC 60068
UNIT
mm
μF
%
V
°C
h
VALUE
10 x 12.5 to 18 x 31.5
1.0 to 150
± 20
200 to 450
- 25 to 105
10 000
IEC 60384-4/EN130300
25/105/56
SELECTION CHART FOR C
R
, U
R
, AND RELEVANT NOMINAL CASE SIZES
(Ø D x L in mm)
C
R
(μF)
1.0
2.2
3.3
4.7
6.8
10
22
33
47
68
100
150
RATED VOLTAGE (V)
200
10 x 16
10 x 20
12.5 x 20
12.5 x 25
16 x 25
18 x 25
250
10 x 12.5
12.5 x 20
12.5 x 25
16 x 25
18 x 25
-
350
10 x 12.5
12.5 x 20
16 x 20
16 x 25
18 x 25
-
-
400
10 x 12.5
10 x 12.5
10 x 16
10 x 16
10 x 20
12.5 x 25
16 x 25
18 x 25
-
-
-
450
-
10 x 16
10 x 16
10 x 20
10 x 20
12.5 x 20
16 x 25
18 x 25
18 x 31.5
-
-
-
Revision: 08-Feb-12
Document Number: 25145
1
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
EKV
www.vishay.com
Vishay Roederstein
RADIAL STYLE: DIMENSIONS
in millimeters
Ø d ± 0.05 tinned copper-ply steel
Ø D +
α
max.
+
S ± 0.5
-
L +
β
max.
15 min.
4 min.
ØD
S
Ød
5
2.0
0.5
6.3
2.5
0.5
1.5
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
2.0
18
7.5
0.8
22
10.0
1.0
25
12.5
1.0
0.5
1.0
DIMENSIONS
in millimeters
AND AVAILABLE FORMS
Casing Insulation
D
max.
Ød
D
max.
S
± 0.5
L
max.
15 min.
4 min.
L
max.
4.5 ± 0.5
Ø D ≤ 18 long leads MALREKV00...
Ø D ≤ 18
shortened
leads MALREKV05...
(S = 2 mm/2.5 mm/3.5 mm/5 mm/7.5 mm)
GENERAL NOTE
• For Minimum Package Quantity (MPQ) and Minimum Order Quantity (MOQ) please refer to our price list or contact customer service.
• For other packaging forms please refer to Vishay Roederstein General Information.
ELECTRICAL DATA
SYMBOL
U
R
C
R
tan
R
ESR
I
R
Rated voltage
Rated capacitance at 120 Hz
Max. dissipation factor at 120 Hz
Max. equivalent series resistance at 120 Hz
Rated alternating current (RMS) at 120 Hz and
upper category temperature
DESCRIPTION
ORDERING EXAMPLE
EKV 22 μF/450 V, ± 20 %, size: 16 mm x 25 mm
Leads: Long
Ordering code: MALREKV00JG222P00K
Leads: Short
Ordering code: MALREKV05JG222P00K
Note
• Unless otherwise specified, all electrical values apply at
T
amb
= 20 °C, P = 80 kPa to 120 kPa, RH = 45 % to 75 %.
Revision: 08-Feb-12
Document Number: 25145
2
For technical questions, contact:
aluminumcaps1@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
