ATTENUATORS
SMA - w/mounting holes, up to 18 GHz, 20 Watts
SPECIFICATIONS:
Models: 2066-XX dB and 2099-XX dB
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values
Attenuation Accuracy
3 & 6 dB
10 & 20 dB
30 & 40 dB
VSWR
DC - 12.4 GHz
12.4 - 18 GHz
Input Power
Peak Power
Impedance
Operating Temp Range
DC - 18 GHz
1 and 18 GHz
2.4
0, 3, 6, 10, 20, 30 & 40 dB
DC - 1 GHz
2.4
1
2.4 - 18 GHz
±0.5 dB
±0.75 dB
±0.75 dB
±1.00 dB
±1.00 dB
±1.50 dB
1.30:1 Max.
1.40:1 Max.
20 Watts Avg. @ 40°C
Derated Linearly to 5 Watts @ +1 C
25
o
500 Watts Max.
(5uSec Pulse, .05% Duty Cycle)
50 Ohms
-65°C to +125°C
Passivated Stainless Steel
Gold Plated Beryllium Copper
Black Anodized Aluminum
Connector
Configuration
Male/Female
Male/Male
Female/Female
LENGTH
Inches
Millimeters
[80.26 ±1.27]
3. 6 ±.05
1
[83.57 ±1.27]
3.29 ±.05
[76.96 ±1.27]
3.03 ±.05
Mechanical:
SMA Connectors
Mates with MIL
-STD-348
Conductors
Housing
SMA FEMALE
2.29 [58.17]
SMA MALE
4-40UNC-2B STAINLESS
STEEL THREADED INSERT
TYPICAL - 4 PLACES
.700
[17.78]
14X Ø.50
[12.7]
.50
[12.7]
1.00
[25.4]
.150
[3.81]
2.000
[50.8]
SEE TABLE
.145 [3.68]
.50
[12.7]
1.00
[25.4]
HOW TO ORDER:
Model Number:
20XX-XXY
Freq. Range
66 = DC - 1 GHz
2.4
99 = DC - 18 GHz
Connector Configuration
= Male/Female
F = Fem/Fem
M = Male/Male
dB Value
Ordering Examples:
Model Number:
2066-20
DC - 1 GHz; 20 dB; SMA - Male/Fem
2.4
Model Number:
2099-06F
DC - 18 GHz; 6 dB; SMA - Fem/Fem
Model Number:
2066-03M
DC - 1 GHz; 3 dB; SMA - Male/Male
2.4
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design specifications are subject to change without notice.
Contact factory for technical specifications before purchasing or use.
2066: REV G
Aeroflex / Inmet, Inc.
300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex.com/inmet
