Low-Loss Filter for Mobile Communication
Data Sheet
B4154
1960,0 MHz
Ceramic package
DCC6D
Features
s
Low-loss RF filter for mobile telephone
s
s
s
s
s
PCS systems, receive path
Low amplitude ripple
Usable passband 60 MHz
Unbalanced to balanced operation
Package for
Surface Mounted Technology
(SMT)
Ceramic SMD package
Terminals
s
Gold-plated Ni
Dimensions in mm, approx. weight 0,037 g
Pin configuration
2
4, 6
1, 3, 5
Input, unbalanced
Output, balanced
Ground, to be grounded
Type
B4154
Ordering code
B39202-B4154-U510
Marking and Package
according to
C61157-A7-A68
Packing
according to
F61074-V8089-Z000
Electrostatic Sensitive Device
(ESD)
Maximum ratings
Operating temperature range
T
Storage temperature range
T
stg
DC voltage
V
DC
Input power max.
– 30 / + 85
– 40 / + 85
5
0
˚C
˚C
V
source and load impedance 50
Ω
dBm
peak power of TDMA signal,
duty cycle 1 : 3
P
IN
2
Jul 11, 2000
SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
Characteristics
Operating Temperature Range:
Terminating source impedance:
Terminating load impedance:
B4154
1960,0 MHz
T
= -30 to +85˚C
Z
S
= 50
Ω
(unbalanced)
Z
L
= 50
Ω
(balanced)
min.
typ.
1960,0
max.
—
MHz
Center frequency
Maximum insertion attenuation
1930,0 ... 1990,0
Amplitude ripple
(p-p)
1930,0 ... 1990,0
Attenuation
0,0
1000,0
1830,0
1850,0
1900,0
2020,0
2060,0
2200,0
2260,0
4000,0
4500,0
... 1000,0
... 1830,0
... 1850,0
... 1900,0
... 1910,0
... 2060,0
... 2200,0
... 2260,0
... 4000,0
... 4500,0
... 6000,0
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
f
C
α
max
MHz
∆α
MHz
α
—
—
3,6
4,5
dB
—
0,9
1,8
dB
50
40
30
10
8
10
25
40
25
20
15
56
50
50
19
16
17
32
47
42
33
30
—
—
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
dB
3
Jul 11, 2000
SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
Transfer function
(three port measurement)
B4154
1960,0 MHz
Transfer function
(wideband)
4
Jul 11, 2000
SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
B4154
1960,0 MHz
