CKR60 Series
PRODUCT SELECTION
Description
4.5-32 VDC Control
90-280 VAC Control
18-36 VAC Control
AVAILABLE OPTIONS
CKRD6010
CKRA6010
CKRA6010E
10 A
CKRD6020
CKRA6020
CKRA6020E
20 A
CKRD6030
CKRA6030
CKRA6030E
30 A
OUTPUT SPECIFICATIONS (1)
Description
Operating Voltage (47-63Hz) [VRMS]
Transient Overvoltage [Vpk]
Maximum Off-State Leakage Current @ Rated Voltage [mArms]
Minimum Off-State dv/dt @ Maximum Rated Voltage [V/µsec] (2)
Maximum Load Current (3) [Arms]
Minimum Load Current [Arms]
Maximum Surge Current (16.6ms) [Apk]
Maximum On-State Voltage Drop @ Rated Current [Vpk]
Maximum I²t for Fusing (8.3 msec) [A² sec]
Minimum Power Factor (with Maximum Load)
48-660
1200
1.0
500
10
0.15
120
1.6
60
0.5
48-660
1200
1.0
500
20
0.15
250
1.6
260
0.5
48-660
1200
1.0
500
30
0.15
625
1.6
1620
0.5
INPUT SPECIFICATIONS (1)
Description
Control Voltage Range
Maximum Turn-On Voltage
Minimum Turn-Off Voltage
Typical Input Current (4)
4.0-32 VDC
4.0 VDC
1.0 VDC
8-12 mA
1/2 Cycle
1/2 Cycle
90-280 Vrms
90 Vrms
10 Vrms
2 mA @ 120 Vrms, 4 mA @ 240
Vrms
10
40
18-36 Vrms
18 Vrms
4.0 Vrms
10 mA @ 24 Vrms
10
40
GENERAL SPECIFICATIONS
Description
Dielectric Strength, Input/Output/Base (50/60Hz)
Minimum Insulation Resistance (@ 500 V DC)
Maximum Capacitance, Input/Output
Ambient Operating Temperature Range
Ambient Storage Temperature Range
Status Indicator Display
Weight (typical)
Encapsulation
Terminals
Maximum Wire Size:
Recommended Terminal Screw Torque Range:
Min. Side by Side Spacing
Maximum Turn-On Time [msec] (3)
Maximum Turn-Off Time [msec]
4000Vrms
10 9 Ohms
8 pF
-40ºC to 80ºC
-40ºC to 125ºC
Green LED
10 oz. (280g)
Thermally Conductive Epoxy
Box Clamp Type
AWG # 10 (3mm)
5.0-6.0 in lb (0.6-0.7 Nm)
0.8 inch (20mm)
Parameters
