100GHz Compact Fiber
Optical Interleaver
CFOI100GHz
Oplink’s compact, low-dispersion interleavers greatly expand wavelength chan-
nel counts in DWDM systems. Oplink’s DWDM interleavers feature excellent
wide, flat passbands and high isolation. Both mux and demux functions are
supported. Interleavers are athermal and do not require temperature control.
Performance Specifications
Parameter
Min.
Typical
Max.
Unit
Central Wavelength Range (C-band)
Central Frequency Range (C-band)
Central Wavelength Range (L-band)
Central Frequency Range (L-band)
Channel Center Wavelength
Input Channel Spacing
Output Channel Spacing
Clear Bandwidth
Insertion Loss
1
Ripple
Insertion Loss Uniformity
Adjacent Channel Isolation
Polarization Dependent Loss (PDL)
Polarization Mode Dispersion (PMD)
Chromatic Dispersion
Return Loss
Directivity
Operating Power Handling
Operating Temperature
Storage Temperature
Fiber Type
Packaging Dimensions
3
1529.55
192000
1569.59
186900
ITU Grid
100
200
+/-15
1.5
0.2
0.3
25
0.3
0.2
-20
45
50
0
-40
50
55
1561.42
196000
1604.03
191000
nm
GHz
nm
GHz
GHz
GHz
GHz
dB
dB
dB
dB
dB
ps
ps/nm
dB
dB
dBm
°C
°C
mm
Features
Low Insertion Loss
High Isolation
Low Dispersion
Highly Stable & Reliable
Epoxy-Free Optical Path
Compact Size
Completely Passive
Athermal Design
Applications
DWDM Systems
Extend Network Capacity
1.8
0.4
0.5
0.4
0.3
+20
24
65
+85
Corning SMF-28
100 (L) x 28 (W) x 12 (H)
Note:
1. The maximum IL is under all states of polarization and within the full operating temperature and wavelength ranges
specified.
2. All the parameters are excluding connectors.
3. The mechanical tolerance should be +/-0.2mm on all package dimensions unless otherwise custom specified.
Oplink Communications, Inc.
R6.20080410
100 GHz Compact Fiber Optical Interleaver
CFOI100 Series
Mechanical Drawing / Package Dimensions
(dimension in mm)
46335 Landing Parkway Fremont, CA 94538-6407 Tel: (510 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink's OEM design team
or account manager for your requirements and ordering information (510) 933-7200.
CFOI
1
0
0
2
0
0
W
Input
100GHz= 100
Output
200GHz= 200
Band
C band= C
L band= L
Fiber Length
1.0 meter= 1*
1.5 meter= 5
2.0 meter= 2
Fiber Jacket
SMF-28 250µm bare fiber= 1
SMF-28 with 900µm loose tube= 2
Connector
Type
None= 1
FC/PC= 2
FC/SPC= 3
FC/APC= 4
SC/PC= 5
SC/SPC= 6
SC/APC= 7
ST= 8
LC= 9
MU= A
* The tolerance of fiber length is +/-0.1m. 1 meter is standard. The lead-time for special fiber length will be longer.
R6.20080410
Product Lines
Mux/Demux
Switching/Routing
Coupling/Splitting
Monitoring/Conditioning
Amplification
Transceivers
Interconnect
RGB Laser Modules
