3T SERIES
Single output
•
•
•
•
•
•
•
75% efficiency
UL and CSA approvals
Adjustable output voltage
Logic inhibit
Short circuit protection
Parallelability
Remote sense
These wide range input, three terminal, 25kHz switching regulators are versatile,
inexpensive, and efficient. They provide a single adjustable output from a DC
source. 75% typical efficiency is an added advantage of the switcher which
helps reduce transformer and heatsink requirements over an equivalent linear
regulator. Since their efficiency is essentially independent of input voltage,
output current need not be derated with increasing input voltage. Other
features include: short circuit protection; remote on/off; parallelability and
remote sensing. The 3T Series modules are unique open board DC/DC
converters that help solve tough power system requirements.
[ 2 YEAR WARRANTY ]
SPECIFICATION
OUTPUT SPECIFICATIONS
Output voltage
(Adjustable)
Remote sense
Line regulation
+10V to +60V
(See Note 1)
Load regulation
Ripple and noise
3T12AP
3T20AP
3T5AN
3T12AP
3T20AP
3T5AN
All specifications are typical at nominal input, full load at 25°C unless otherwise stated
GENERAL SPECIFICATIONS
+4.5VDC to +30VDC
+4.5VDC to +15VDC
–4.5VDC to –30VDC
Remove JP1 for remote
sense operation
See Figure 2
See Figure 2
±0.2%
±1.0%
Efficiency
Switching frequency
Approvals and
standards
Weight
3T12AP
3T20AP
3T5AN
MIL-HDBK-217C
75% typical
25kHz
UL478
CSA C22.2-234 No. 950
0.30kg (10.59oz)
0.40kg (14.12oz)
0.35kg (12.36oz)
95,000 Hours
NL to FL (See Note 2)
3T12AP
3T20AP
3T5AN
+5V (8A to 16A)
MTBF
150mV Pk-Pk, max.
150mV Pk-Pk, max.
250mV Pk-Pk, max.
ENVIRONMENTAL SPECIFICATIONS
Thermal performance
Operating ambient:
3T12AP, 3T5AN
3T20AP
Non-operating
3T12AP, 3T5AN
3T20AP
Non-condensing
Operating
Non operating
0°C to +50°C
0°C to +70°C
–20°C to +85°C
+60°C
+80°C
5% to 80% RH
10,000 feet max.
30,000 feet max.
Transient response
(3T20AP)
200mV pk transient,
1ms recovery to 1%
+15V (8A to 16A) 350mV pk transient,
0.8ms recovery to 1%
±3mV/°C
Minimum
3T12AP
3T20AP
3T5AN
3V(Vin
≥15V),
5V(Vin<15V)
3.5V(Vin
≥15V),
5V(Vin<15V)
See Figure 1
17A ±10%
24A to 27A
8A ±15%
Standard
1
2
3
Maximum heatsink
temperature
Relative humidity
Altitude
Notes
Temperature coefficient
Input/output voltage
differential
Output current limit
(Factory set)
Soft start
3T12AP
3T20AP (See Note 3)
3T5AN
INPUT SPECIFICATIONS
Input voltage range
Remote ON/OFF
See Figure 1
Inhibit
Operate
10VDC to 60VDC
>3V
<1V
Line regulation is over the full +10V to 60V input range.
Load regulation is over the range of no load to maximum average output
current.
The current limit of 3T20AP is factory set at 24A to 27A. However, when
units are used in parallel configuration, the current limit should be set at
20A. Consult factory for a full explanation of parallel operation of 3T
regulators.
International safety standard approvals
UL478 Reg. File No. E131987
CSA C22.2-234 No. 950 File No. LR41062C
Electrical Bulletin No. 1402C
Data Sheet © Artesyn Technologies® 2000
The information and specifications contained in this data sheet are believed to be correct at
time of publication. However, Artesyn Technologies accepts no responsibility for consequences
arising from printing errors or inaccuracies. Specifications are subject to change without notice.
No rights under any patent accompany the sale of any such product(s) or information contained
herein.
PAGE 158
DC/DC CONVERTERS
|
150-360W DC/DC
150 to 360 Watt
Non-isolated DC/DC regulators
INPUT
VOLTAGE
+10V to +60VDC
+10V to +60VDC
+10V to +60VDC
OUTPUT
VOLTAGE
+4.5 to 30V
+4.5 to 15V
–4.5 to –30V
OUTPUT
CURRENT
0-12A
0-20A
0-5A
NO LOAD
INPUT CURRENT
40mA
40mA
40mA
TYPICAL
EFFICIENCY
75%
75%
75%
MODEL
NUMBER
3T12AP-6130
3T20AP-6115
3T5AN-6130
Figure 1 : Min. required input voltage: 3T5AN-6130
Figure 1
60V
30V
INPUT VOLTAGE
5A
4A
3A
2A
10V
Figure 2 : Line Reg. 3T12AP-6130 & 3T20AP-6115
Figure 2
LINE REGULATION
20V
1.0%
0.5%
0
-20V
-10V
OUTPUT VOLTAGE
-30V
9V
10V 11V 12V 13V 14V 15V 16V
INTPUT VOLTAGE
60V
Dimensions : 3T5AN-6130
0.25
(6.40) 2 PL
4.50
(114.30)
Dimensions : 3T12AP-6130 & 3T20AP-6115
0.20
(5.00)
0.25
(6.40) 2 PL
4.50
(114.30)
B
E7
E4
0.20
(5.00)
E
E9
Pot (R13)
Voltage Adj.
Current
Limit
E4
JP
JP
JP2
JP1
E2
5.25
(133.40)
5.05
(128.27)
A
5.25
(133.40)
5.05
(128.27)
D
E2
Pot (R13)
Voltage Adj.
Current
Limit
E1
See Pin
Chart
E3
E3
E1
See Pin
Chart
0.15
(3.80)
1.20
(30.50)
1.00
(25.40)
0.40
(10.10)
5.00
(127.00)
0.15
(3.80)
1.00
(25.40)
0.40
(10.10)
5.00
(127.00)
1.25
(31.80)
1.20
(30.50)
0.156 6 Places
(4.000)
0.30
(7.60)
1.25
(31.80)
0.156 6 Places
(4.000)
0.30
(7.60)
5
1.55 Max.
(39.40)
0.50
(12.70)
1.65
(41.90)
1.55 Max.
(39.40)
0.50
(12.70)
1.65
(41.90)
ALL DIMENSIONS IN INCHES (mm)
ALL DIMENSIONS IN INCHES (mm)
PIN CONNECTIONS (3T5AN)
PIN
E1
E2
E3
E4
E5
FUNCTION
+ Input
– Output
Return
+ Remote Sense
– Remote Sense
NOTE
C
C
C
A
PIN CONNECTIONS
(3T12AP AND 3T20AP)
PIN
FUNCTION
NOTE
E1
+ Input
F
E2
E3
E4
E5
E6
E7
E8
E9
+ Output
Return
– Remote Sense
+ Remote Sense
Pos. Sync Out
Neg. Sync Out
Sync In
Inhibit
(Remote On/Off)
F
F
D
G
G
E
E6 Inhibit (Remote On/Off)
E7
Sync In
B
Mechanical notes for 3T5AN
A Remove JP1 for remote sense.
B Remove JP2 to synchronise 3T5AN to 3T12AP or 3T20AP.
C Terminals are 8-32 studs, 8 to 12 in-lbs torque required.
D
E
F
G
Mechanical notes for 3T12AP and 3T20AP
Remove JP1 for remote sense.
Remove JP2 to synchronise to another to 3T12AP or 3T20AP.
Terminals are 8-32 studs, 8 to 12 in lbs torque required.
E6 output is used as clock to synch other 3T12AP’s or 3T20AP’s to a
single 3T12AP or 3T20AP. E7 is used to synch 3T5AN’s to a single 3T12AP
or 3T20AP.
DS_3T_20000101.PDF
http://www.artesyn.com
PAGE 159
