3RU Model 3029T with Model 3030 Receiver
Monitoring and Control
of RF/Optical Systems
3000 Series Modules
The Force
Smart IFL
Model 3029 Medium Range L-Band
Satellite Transmitter is designed work with the Model
3030 Receiver to transport 50 Ohm signals in the 850 to
2500 MHz range for satellite uplink or downlink
applications up to 2 km. The link may be ordered in a
stand-alone or 3RU rack-mount configuration. The 3RU
configuration rack-mounts up to eight hot-swappable
transmitters and/or receivers and two power supplies in a
3RU 19" rack chassis for increased system reliability. The
Model 3029 provides the user with manual gain control
which allows the user to tailor the module input and output
levels to maintain consistent performance. Available with
1310 nm Fabry-Perot (FP) optics, the Model 3030 can be
configured to meet almost any medium range design
need. Indicator LEDs for Laser Status, RF Level, and
Local/Remote Operation (Tx), as well as an indicator for No
Optical (or low optical) input (Rx) allow the user to quickly
assess the link’s operational status. The 3RU version may
be used with Force's SNMP compatible power supplies for
SNMP monitoring and control of the link. As part of the
3000 Series L-Band and IF family, the Model 3029
provides the professional satellite operator a high
performance solution for satellite communications.
TM
MONITORING
SNMP
MANAGEMENT
TOOL
MONITORING
CONTROL
REMOTE PC
3000 Series Modules
with 3000 3RU Chassis
and SNMP Power Supply
825 Park Street, Christiansburg, VA 24073 • USA (800) 732-5252 • TEL (540) 382-0462 • FAX (540) 381-0392 •csr-sales@forceinc.com • www.forceinc.com
© 2005 by Force, Incorporated. Force, Incorporated reserves the right to make changes to the product described in this document in the interest of product improvement. All rights reserved.
CONTROL
Specifications and Ordering Information
Optical and RF Characteristics
Output Wavelength
Tx Optical Output Power
Rx Optical Input Power
Optical Loss Range
I/O Impedance
Frequency Range
Flatness (850-2500 MHz)
Flatness (950-2150 MHz)
Flatness
(any 36 MHz, 850-2500 MHz)
Flatness
(any 36 MHz, 950 -2150 MHz)
RF Gain Variation Over Temp
Link RF Gain (Sm. Ap.)
Link RF Gain (Lg. Ap.)
RF Input Range (Sm. Ap.)
RF Input Range (Lg. Ap.)
Input 1 dB Compression Point
Output 1 dB Compression Point
System Output OIP3
Noise Figure (0 dB Opt. Loss)
Noise Figure (6 dB Opt. Loss)
Intermodulation Products
SDFR (0 dB Opt. Loss)
SDFR (6 dB Opt. Loss)
Input/Output Return Loss
Input/Output VSWR
Group Delay Variation
1.
2.
3.
4.
5.
Electrical Characteristics
Max
1340
+4
+4
2
Units
nm
dBm
dBm
dB
Ohms
MHz
dB
dB
dB
dB
dB
dB
dB
dBm
dBm
dBm
dBm
dBm
dB
dB
dBc
dB/Hz
dB/Hz
dB
ns
Min
Power Supply Voltage
Tx Supply Current
Rx Supply Current
140
180
Typ
+20
Max
185
220
Units
VDC
mA
mA
Min
1280
+2
-4
0
850
Typ
1310
+3
50
3000
±1.25 ±1.5
±0.75 ±1.00
±0.35
± 0.25
-2
0
+2
+10
0
-40
-15
-25
0
-7
-5
+8 +10
+18 +20
23
25
27
29
-55
-50
106
109
103
106
12
14
1.5
1.7
1.0
Physical Characteristics
Typ
Max
3RU Module Weight
8
227
3RU Module Dimensions
5.06 x 1.39 x 12.00
129 x 36 x 305
Stand-alone Module Weight
2
0.91
Stand-alone Module Dimensions 4.36 x 1.26 x 11.50
111 x 32 x 292
Min
Units
oz
g
in.
mm
lbs.
kg
in.
mm
Environmental Characteristics
Min
Operating Temperature Range -10
Storage Temperature Range
-40
Humidity (RH, non-condensing) 5
Typ
Max
+55
+60
95
Units
°C
°C
%
Link gain can be adjusted to specified limits up to a maximum loss of 6 dB (12 km).
The Optical Loss knob controls the link gain over the full optical loss range.
Optimal ranges are: -15 to -35 dBm, small aperture and 0 to -20 dBm, large aperture.
SFDR = 2/3 (Input Third Order Intercept (dBm) - Equivalent Input Noise (dBm/Hz)).
This Product Conforms to the Electromagnetic Compatibility Requirements in
accordance with European Community Directive #89-336-EEC.
Medium Range L-Band Tx and Rx P/N
3030 Tx and Rx Options
Tx, 50 Ohm, 1310 nm,
SM, SC/APC
Rx, 1310/1550 nm,
SM, SC/APC
3RU Rack-mount Stand-alone 3RU Rack-mount
Small Aperture Small Aperture Large Aperture
3029TA-SCSP
1
3030RA-SFSP
1
3029TB-SCSP
1
3030RB-SFSP
1
3029TC-SCSP
1
3030RA-SFSP
1
Stand-alone
Large Aperture
3029TD-SCSP
1
3030RB-SFSP
1
3RU Model 3029 Transmitter and Model 3030 Receiver Panels
1. FC/APC connectors are also available. Replace SP in the part number with AP.
3RU Chassis and all Power Supplies
Chassis, Power Supply and Panel Options
3RU Chassis, Holds 8 Modules and 2 P.S.
3RU Power Supply, Universal AC
3RU Power Supply, -48 Volts DC
Wall-mount Power Supply, +20 Volts DC,
1.5A, Used with Stand-alone Units
Part Number
3000CB-NN
3000UC-NN
3000UE-NN
PS3000
Stand-alone Model 3030 Transmitter
Rev. 3.0 08/04/05
