mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
Type
square pins
.8 mm square
383
Terminal block that mates with
Type 383
Type 369
ASP06
Type 393
Type 379
Page DB-3
Page DB-3
Page EB-2
393
300 V
8A
.8 mm square - mating
.8 mm square - solder
1.5 mm
3.25 mm
with mounting flange
square pins
.8 mm square
Electrical Data
Voltage
Current
Square pins
PCB hole diameter
Solder pin length
Electrical Data
Voltage
Current
Square pins
PCB hole diameter
Solder pin length
300 V - 3.81 mm
8A
.8 mm square - mating
.8 mm square - solder
1.5 mm
3.25 mm
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
copper alloy
2 to 24
Additional data - page H-3
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
copper alloy
2 to 24
Additional data - page H-3
Note
for
Type 383
and
Type 393
without any circuit loss codable
coding set 720293-01-0
Page J-9
Color
Pin
Pole sizes
Color
Pin
Pole sizes
Dimensions (mm)
Dimensions (mm)
L = (circuits - 1) x centerline + 5.2
L = (circuits - 1) x centerline + 13.95
Part Numbers
Type 383
Complete the part number
by adding the pole size.
centerline 3.81 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
Type 393
Complete the part number
by adding the pole size.
centerline 3.81 mm
Part No.
313831
Part No.
313931
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
