ATTENUATORS
SMA, up to 6 GHz, 100 Watts
SPECIFICATIONS:
Models: XB100W-XX, XB100W-XXF & XB100W-XXM
Electrical:
Frequency Range
Standard Freq. Values
Standard dB Values*
Attenuation Accuracy
1 - 6 dB
10 - 40 dB
VSWR (Max.)
Input Power
Reverse Power
Peak Power
Impedance
Operating Temp Range
DC - 6.0 GHz
1.5, 3 & 6 GHz
3, 6, 10, 20, 30 & 40** dB
1.5 - 2.5 GHz
2.5 - 6 GHz
±0.50 dB
±0.75 dB
±1.0 dB
±1.5 dB
1.25:1
1.35:1
100 Watts Avg.
20 Watts Max.
2 kW Max.
Derated Linearly to 20 Watts @ +125 C
o
DC - 1.5 GHz
±0.50 dB
±0.75 dB
1.15:1
Custom Mtg. hole Config.
may be Added to this
Surface
3.46±.02
[87.88±0.51]
SQUARE
50 Ohms
-54°C to +125°C
Passivated Stainless Steel
Gold Plated Beryllium Copper
Anodized Aluminum
Mechanical:
SMA Connectors
Mates with MIL-STD-348
Conductors
Housing
END VIEW
TYPICAL
Units must be Mounted in such a way as to
Allow for Free Air Flow Around fins to Assure
Performance
**40 dB Units are only available up to 4 GHz
Note: Units are Unidirectional, Therefore Input Connector MUST be specified & will be Indicated on Unit
Model Number:
XB100W-XX
Male/Female Connectors
Length: 5.66 ±.05 [143.8 ±1.3]
Pictured
5.66 ±.05
[143.8 ±1.3]
1.75
[44.45]
Model Number:
XB100W-XXF
Female/Female Connectors
Length: 5.52 ±.05 [140.2 ±1.3]
INPUT
Model Number:
XB100W-XXM
Male/Male Connectors
Length: 5.79 ±.05 [147.1 ±1.3]
.23 [5.8]
2X M4x0.7 TAP
x .50 [12.7] DP.
2X 8-32UNC-2B TAP
x .50 [12.7] DP.
Ordering Examples:
Model Number:
1B100W-1
DC - 1.5 GHz, 1 dB; SMA - Male/Fem
Connector Configuration
= Male/Female
F = Fem/Fem
M = Male/Male
Model Number:
3B100W-3F
DC - 3 GHz, 3 dB; SMA - Fem/Fem
HOW TO ORDER:
Model Number:
XB100W-XXY
Model Number:
6B100W-20M
DC - 6 GHz, 20 dB; SMA - Male/Male
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
*Other dB also available. Units that operate over a more specific wave band and/or offer very low
XB100W: REV M
return loss (VSWR) or offer higher peak power are available.
dB Value
Freq. Range
1 = DC - 1.5 GHz
3 = DC - 3 GHz
6 = DC - 6 GHz
Aeroflex / Inmet, Inc.
• 300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex-inmetcorp.com • sales@aeroflex-inmetcorp.com
