CCJ Series • Compact SMD Common Mode Chokes

Features

• Low cost, compact SMD for pick and place compatability

while providing consistent and reliable coplanarity

• High attenuation over a wide frequency range

• Manufactured in ISO-9001 approved Talema facility

• Other inductance values available upon request

Electrical Specifications

Ratings @ 25°C ambient

Operating Temperature: 0 to 70°C

Storage Temperature: -25° to +105°C

Test voltage between windings: 500 Vrms

Test frequency: Inductance measured @ 100kHz/20 mVrms

C C J Series • C ompact D ouble and Quad C hokes for D ata and Signal Line EMI Suppression

Part N umber

N umber of

D ata Lines

OC L

(µH ±30% )

(mA)

DCR

(mOhms Typ.)

N umber

of C oils

Windings

per C ore

Schematic

D ouble C hokes

C C J-2-260

C C J-2-102

C C J-2-152

C C J-2-222

C C J-2-332

C C J-2-502

C C J-2-682

C C J-2-103

C C J-2-123

C C J-2-283

C C J-2-503

C C J-2-703

1000

1500

2200

3300

5000

6800

10000

12000

28000

50000

70000

900

550

500

450

400

270

200

170

140

100

115

140

180

200

250

270

520

970

1490

Quad C hokes • 4 w indings per core

C C J-4-260

C C J-4-470

C C J-4-101

C C J-4-221

C C J-4-471

C C J-4-681

C C J-4-102

C C J-4-152

C C J-4-222

C C J-4-332

C C J-4-502

C C J-4-103

C C J-4-123

C C J-4-583

100

220

470

680

1000

1500

2200

3300

5000

10000

12000

58000

600

500

400

330

400

350

330

230

170

130

190

120

140

170

120

140

180

220

430

770

2350

Quad C hokes • 2 cores w ith double w indings

C C J-4-250C

C C J-4-101C

100

650

450

110

220

0.551 0.472

(14.00) (12.00)

TALEMA IN

WK/YR

Part Number

Suggested Pad

Layout

0.300

(7.62)

Schematics

0.100

(2.54)

0.300

(7.62)

0.433

(11.00)

0° - 8°

0.590

(15.00) 0.102

(2.60)

0.047

(1.20)

0.354 0.315

(9.00) (8.00)

0.020 x 0.12

(0.50 x 0.30)

Dimensions: Inches (Millimeters)

Tolerance: ±0.010 (0.25)

Surface Coplanarity will be 0.004(0.10) maximum
