VARIABLE COILS
Dimensions in inches (mm)
Core Material
-01 to -13 Carbonyl SF
-14 to -25 Carbonyl TH
-26 to -37 Carbonyl E
-38 to -49 Carbonyl C
(Blue)
(Purple)
(Red)
(Yellow)
How to order code
558 - 7107 - XX - 00 - 00
Basic Part No.
Inductance Code
Basic Part
No.
-01
-02
-03
-04
-05
-06
-07
-08
-09
-10
-11
-12
-13
-14
-15
-16
-17
-18
-19
-20
-21
-22
-23
-24
558-7107
-25
-26
-27
-28
-29
-30
-31
-32
-33
-34
-35
-36
-37
-38
-39
-40
-41
-42
-43
-44
-45
-46
-47
-48
-49
Inductance (μH)
Min.
Max.
0.090
0.110
0.108
0.136
0.135
0.165
0.162
0.198
0.198
0.245
0.245
0.297
0.297
0.363
0.351
0.429
0.423
0.517
0.504
0.616
0.612
0.748
0.738
0.902
0.900
1.10
1.08
1.36
1.35
1.65
1.62
1.98
1.98
2.45
2.43
2.97
2.97
3.63
3.51
4.29
4.23
5.17
5.04
6.16
6.12
7.48
7.38
9.02
9.00
11.0
10.8
13.6
13.5
16.5
16.2
19.8
19.8
24.5
24.3
29.7
29.7
36.3
35.1
42.9
42.3
51.7
50.4
61.6
61.2
74.8
73.8
90.2
90.0
110
108
136
135
165
162
198
198
245
243
297
297
363
351
429
423
517
504
616
612
748
738
902
900
1100
"Q"
at L Min.
65
65
70
70
70
70
70
70
70
70
70
70
70
55
50
50
50
50
50
50
50
50
55
55
55
55
60
60
65
65
65
60
55
50
50
45
45
45
50
50
50
50
45
45
40
35
35
30
30
"Q"
at L Max.
65
65
70
70
70
70
70
70
70
70
70
65
65
50
45
40
40
40
45
45
50
50
55
55
55
60
70
70
70
70
70
65
60
55
55
50
45
50
60
60
60
55
50
50
45
45
40
35
35
Test
Frequency (MHz)
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
25.0
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
0.79
DCR Max.
(Ω)
0.031
0.034
0.037
0.049
0.055
0.061
0.067
0.073
0.080
0.093
0.093
0.100
0.110
0.130
0.140
0.200
0.260
0.380
0.510
0.700
0.880
1.30
1.70
1.90
2.00
2.10
2.20
2.30
2.50
2.70
3.00
3.50
3.60
4.00
4.30
6.40
8.50
9.30
10.0
11.0
12.0
22.0
23.0
26.0
28.0
33.0
39.0
49.0
60.0
DC Max.
(mA)
2200
2100
2000
1750
1600
1500
1450
1400
1350
1300
1250
1200
1100
1000
1000
900
800
700
600
500
400
360
280
270
260
255
250
240
230
220
210
200
190
180
170
160
150
145
140
130
120
90
85
80
75
65
60
55
55
SRF Min.
(MHz)
250
250
250
250
250
250
230
220
210
200
173
150
130
120
110
100
88
83
78
71
64
58
52
46
40
11
10
9.5
9.0
8.5
8.0
7.5
6.4
5.7
4.9
4.6
4.3
3.8
3.5
3.3
3.1
2.9
2.7
2.3
1.9
1.7
1.5
1.3
1.2
Temperature Range:
-55
0
C to +105
0
C
For RoHS Compliant add suffix -LF to the part number
Windings are varnish impregnated and powdered iron cores
are moisture proofed
Recommended tuning tool 435-1522-01-00-00
