87520-1010A datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> 87520-1010A

Preview

87520-1010A: DescriptionTelecom and Datacom Connector, 4 Contact(s), Female, Right Angle, Solder Terminal, Receptacle; CategoryThe connector The connector; File Size59KB，2 Pages; ManufacturerAmphenol; Websitehttp://www.amphenol.com/

Download Datasheet Parametric View All

87520-1010A Overview

Telecom and Datacom Connector, 4 Contact(s), Female, Right Angle, Solder Terminal, Receptacle

87520-1010A Parametric

Parameter Name	Attribute value
Maker	Amphenol
Reach Compliance Code	unknown
Body/casing type	RECEPTACLE
Connector type	USB CONNECTOR
Contact to complete cooperation	GOLD (30) OVER PALLADIUM NICKEL
Contact completed and terminated	TIN LEAD (98) OVER NICKEL
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
DIN compliance	NO
empty shell	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYETHYLENE
JESD-609 code	e0
MIL compliance	NO
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Options	GENERAL PURPOSE
Shell surface	NICKEL/TIN
Shell material	COPPER ALLOY
Termination type	SOLDER
Total number of contacts	4
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

Product Datasheet -- USB

Home

> Products > Datasheet

USB Receptacle

87520-1010A

PRODUCT

SEARCH BY

Part Number

USB Type "A" Receptacle

Check Distributor Stock

GO

Product Type

Industry Standard

Product Trade Name

Cross Reference

Alphabetic List

Application Tooling

Catalog Keyword

Document Search

Product Type

Style

Orientation

Mounting Style

Contact Area Plating

Tail Plating

Shell Plating

Shell Options

Housing Color

Housing Material

Features Selected

Receptacle

A

Right angle

Thru-hole

30 µin. GXT

2.50 µm Tin Lead

Nickel and Tin Lead

No Back Shield

Black

Glass fiber filled thermoplastic, UL 94V-0

4

Standard

Tape and Reel

None

QUICK LINKS

Basics+

High Speed

Wejtap

Number of Contacts

Pin Orientation

Hold Down Style

Packaging Options

Mounting Flange/Hole Options

LIBRARY

Product Literature

Technical Library

Recommended PCB Thinckness

USB 2.0 Qualified

Single or Dual Stack

Maximum Panel Thickness

http://ecatalog.fciconnect.com/fci/datasheet.asp?PN=875201010A&FAM=243 (1 of 2)7/5/2004 1:36:05 PM

Other Properties

1.57 mm

Yes

Single

2.67 mm
