3N258: DescriptionBridge Rectifier, Single Phase Full Wave; Max Peak Repetitive Reverse Voltage: 800; Max TMS Bridge Input Voltage: 560; Max DC Reverse Voltage: 800; Capacitance: 25; Package: DIGI M; CategoryDiscrete semiconductor diode; File Size783KB，3 Pages; ManufacturerDigitron; Websitehttp://www.digitroncorp.com

Download Datasheet Parametric Compare View All

3N258 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	3N258	-	-	View	Buy Now

3N258 Overview

Bridge Rectifier, Single Phase Full Wave; Max Peak Repetitive Reverse Voltage: 800; Max TMS Bridge Input Voltage: 560; Max DC Reverse Voltage: 800; Capacitance: 25; Package: DIGI M

3N258 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Digitron
package instruction	R-PSIP-T4
Reach Compliance Code	unknown
Minimum breakdown voltage	800 V
Configuration	BRIDGE, 4 ELEMENTS
Diode component materials	SILICON
Diode type	BRIDGE RECTIFIER DIODE
JESD-30 code	R-PSIP-T4
JESD-609 code	e0
Maximum non-repetitive peak forward current	60 A
Number of components	4
Phase	1
Number of terminals	4
Maximum operating temperature	165 °C
Minimum operating temperature	-55 °C
Maximum output current	2 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum repetitive peak reverse voltage	800 V
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

3N253-3N259

High-reliability discrete products

and engineering services since 1977

FEATURES

•

Available as “HR” (high reliability) screened per MIL-PRF-19500, JANTX level. Add “HR” suffix to base part number.

Available as non-RoHS

(Sn/Pb plating), standard, and as RoHS by adding “-PBF” suffix.

GLASS PASSIVATED SINGLE PHASE BRIDGE RECTIFIER

MAXIMUM RATINGS

Rating

Maximum repetitive peak reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average forward output rectified

current at T

A

= 50°C

Peak forward surge current single half-sine

wave superimposed on rated load

T

J

= 150°C

Rating for fusing (t < 8.3ms)

Typical thermal resistance per leg

(1)

Operating and storage temperature range

Symbol

V

RRM

V

RMS

V

DC

I

F(AV)

3N253

50

35

50

3N254

100

70

100

3N255

200

140

200

3N256

400

280

400

2.0

3N257

600

420

600

3N258

800

560

800

3N259

1000

700

1000

Units

Volts

Amps

I

FSM

I

2

t

R

Ө

JA

R

Ө

JL

T

J

, T

stg

60.0

15.0

30.0

11.0

-55 to +165

Amps

A

2

s

°C/W

°C

Note 1: Thermal resistance from junction to ambient and from junction to lead mounted on PCB with 0.47 x 0.47” copper pads.

ELECTRICAL CHARACTERISTICS (T

C

= 25°C)

Characteristic

Maximum instantaneous forward voltage

drop per leg at 3.14A

Maximum DC reverse current at rated DC

blocking voltage per leg

T

A

= 25°C

T

A

= 125°C

Typical junction capacitance

Symbol

V

F

3N253

3N254

3N255

3N256

1.1

3N257

3N258

3N259

Units

Volts

I

R

5

500

25

µA

C

J

pF

Rev. 20171221
