12 A, 120 V, NPN, Si, POWER TRANSISTOR

Preview

Download Datasheet

View All

INCHANGE Semiconductor

isc

Product Specification

isc

Silicon NPN Darlington Power Transistor

DESCRIPTION

·Collector

Current -I

12A

·Collector-Emitter

Saturation Voltage-

: V

CE(sat)

= 2.0V(Max.)@ I

= 5A

·Complement

to Type BDV64/A/B/C

APPLICATIONS

·Designed

for audio output stages and general amplifier

and switching applications

ABSOLUTE MAXIMUM RATINGS(T

=25

℃)

SYMBOL

PARAMETER

BDV65

Collector-Base

Voltage

BDV65A

BDV65B

VALUE

UNIT

BDV65/A/B/C

CBO

CEO

Collector-Emitter

Voltage

EBO

Emitter-Base Voltage

.cn

.is

100

BDV65C

BDV65

120

BDV65A

BDV65B

100

BDV65C

120

0.5

125

3.5

150

-65~150

℃

Collector Current-Continuous

Collector Current-Peak

Base Current-Continuous

Collector Power Dissipation

@ T

=25℃

Collector Power Dissipation

@ T

=25℃

Junction Temperature

Storage Temperature Range

stg

THERMAL CHARACTERISTICS

SYMBOL

th j-c

th j-a

PARAMETER

Thermal Resistance,Junction to Case

Thermal Resistance,Junction to Ambient

MAX

1.0

35.7

UNIT

℃/W

isc Website：www.iscsemi.cn
