Application Equipment for
Crimp-to-Wire Duramate
TM
Receptacles
Technical Data
OL-740
Application Rate
(crimps/hour)
Air Consumption
Air Pressure
Electrical
Requirements
Machine
Weight
Controller
Weight
Machine
Dimensions
(H x W x D)
2400
N/A
N/A
115 V AC, 60 Hz,
10 amp
95 kg
(209 lb.)
N/A
114 x 51 x 58 cm
(45 x 20 x 23 in.)
Ordering Data
Machines (for strip-form receptacles)
OLYMPIAN Model 740 (press only)
OL-740 Applicators
Hand Tools (for loose-piece receptacles)
HT-153
Description
Customer Product Drawings
Product Specifications
Product Samples
Approvals and Certifications
UL
CSA (Headers)
CSA (Receptacles)
Wire Size (AWG)
–
26-30
–
26-30
Identification Number
133911-002
411231-000
HT-153
Customer Support Materials
Order No.
By Part Number
DPS-12-001
Upon Request
File No. E66906
File No. LR4692
File No. LR 46923
Literature No. 950535-001
May 12, 1994
TM
DURAMATE SYSTEM
Crimp-to-Wire Receptacle, Housing and
Header 2.00mm (0.079 inch) Centerline
TM
Features
Duramate is a highly reliable Interconnect systems
on 2.00mm centres. It features a dual beam
crimp-to-wire receptacle terminal mated with
0.5mm (0.020 in.) square header pin which offers
an excellent electrical and mechanical performance
for wire to board applications.
• Mated height of 9.3mm
• Variety of positions from 2-15
• Choices of vertical or right angle headers
• Polarization prevents mating errors
• Range of wire gauges — 26 AWG to 30 AWG
• “Kinking” feature on board side of header pin
eliminates “floating” during wave soldering
• Retention feature on header body enables
connector to withstand high shock and
vibration without unmating.
DURAMATE
TM
SYSTEM
2.00mm (0.079 inch) Centerline
TM
Technical Data
Spacing
Polarizing
Housing/Header
2.00 mm (0.079 inch)
Configuration of plastic parts
Polyphenylene Oxide (UL 94V-0) Color Beige
Nylon 6,6 (UL 94V-0) Color Beige
1000 MΩ min
-40°C to 105°C
650 V according to MIL-STD-202 Method 301
Phosphor Bronze
Brass
0.8 µm min Tin/Lead
3.0 µm min Tin/Lead
2A continuous, depending on wire size
20 mΩ max
20000 Contacts per reel
2000 Housings or headers per package 2 and 3 positions
1000 Housings or headers per package 4 through 8 positions
500 Housings or headers per package 9 through 15 positions
Contact
Material Housing
Header
Insulation resistance
Temperature range
Withstanding voltage
Material Receptacle
Pin
Finish Receptacle
Pin
Current rating
Resistance
Packaging
Ordering Data
Receptacle
Part Number
78180-101
78180-102
Dim D
0.60/0.024
1.10/0.043
Wire Size AWG
26-30
Insulation OD Size
1.00 -1.40
0.039-0.055
Note:
1) ‘Kinking’ feature for Straight and Right-
angle Header
For 2 positions: Both pins ‘kinked’
3 positions: 1st and last pins ‘kinked’
4-15 positions: 2nd and 2nd last pins ‘kinked’
2) P/N 78180-102 is recommended for shielded
wire applications
Housing and Header
No. of
Pos.
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Housing
78183-002
78183-003
78183-004
78183-005
78183-006
78183-007
78183-008
78183-009
78183-010
78183-011
78183-012
78183-013
78183-014
78183-015
Part Number
Straight
Header
78185-002
78185-003
78185-006
78185-005
78185-006
78185-007
78185-008
78185-009
78185-010
78185-011
78185-012
78185-013
78185-014
78185-015
Right Angle
Header
78186-002
78186-003
78186-004
78186-005
78186-006
78186-007
78186-008
78186-009
78186-010
78186-011
78186-012
78186-013
78186-014
78186-015
Header Width
mm
4.00
6.00
8.00
10.00
12.00
14.00
16.00
18.00
20.00
22.00
24.00
26.00
28.00
30.00
Inches
0.157
0.236
0.315
0.394
0.472
0.551
0.630
0.709
0.787
0.866
0.945
1.024
1.102
1.181
Housing Width
mm
4.40
6.40
8.40
10.40
12.40
14.40
16.40
18.40
20.40
22.40
24.40
26.40
28.40
30.40
Inches
0.173
0.252
0.331
0.409
0.488
0.567
0.646
0.724
0.803
0.882
0.961
1.039
1.118
1.197
Ordering and Technical Information 800-237-2374
