Capacitors with Screw Terminals
Compact
–
105 °C
B43560, B43580
Long-life grade capacitors
Applications
I
Frequency converters
I
Traction
I
Highly professional power supplies
B43560
B43580
Features
I
Maximum reliability
I
Good thermal characteristics and
I
I
I
I
I
KAL0567-B
B43560
B43580
high ripple current capability
Long useful life
Wide temperature range
All-welded construction ensures reliable
electrical contact
Version with optimized construction for base cooling
(2-pad solution) available
Version with low-inductance design available
Construction
I
I
I
I
I
Charge-discharge proof, polar
Aluminum case with insulating sleeve
Poles with screw terminal connections
Mounting with ring clips, clamps or threaded stud
The bases of types with threaded stud and
d
≤
76,9 mm are
not insulated, types with
d
=
91 mm have fully insulated bases
150
10/02
B43560 / B43580
Compact
–
105 °C
Specifications and characteristics in brief
Rated voltage
U
R
Surge voltage
U
S
Rated capacitance
C
R
Capacitance tolerance
Leakage current
I
L
(5 min, 20 °C)
Self-inductance
ESL
350 … 450 VDC
1,10 ·
U
R
(105 °C;
U
R
≤
400 VDC, 85 °C;
U
R
= 450 VDC)
2 200 … 15 000
µF
±
20 %
M
C
R
U
R 0,7
I
L
≤
0,3
µA ⋅
æ
-------
⋅
-------
ö
+
4
µA
è
µF
V
ø
d
= 51,6 mm: approx. 15 nH
d
≥
64,3 mm: approx. 20 nH
Capacitors with low-inductance design:
d
≥
64,3 mm: approx. 13 nH
Useful life
105 °C;
U
R
;
I~
R
85 °C;
U
R
;
I~
R
40 °C;
U
R
; 2,2 ·
I~
R
> 6 000 h
> 20 000 h
> 250 000 h
Requirements:
∆
C
/
C
ESR
I
L
≤ ±
30 % of initial value
≤
3 times initial specified limit
≤
initial specified limit
Failure percentage:
≤
1 %
Failure rate:
≤
20 fit (≤ 20 · 10
–9
/h)
(for definiton “fit”, refer to chapter
“Quality”
, page 62)
Voltage endurance test
105 °C;
U
R
;
I~
R
2 000 h
Post test requirements:
∆
C
/
C
ESR
I
L
≤ ±
10 % of initial value
≤
1,3 times initial specified limit
≤
initial specified limit
Vibration resistance
To IEC 60068-2-6, test Fc:
displacement amplitude 0,75 mm, frequency range 10 to 55 Hz,
acceleration max. 10
g,
duration 3
×
2 h
To IEC 60068-1:
40/105/56 (– 40 °C/+ 105 °C/56 days damp heat test)
Similar to CECC 30301-803, CECC 30301-807
IEC 60384-4
IEC climatic category
Detail specifications
Sectional specification
Ripple current capability
Due to the ripple current capability of the contact elements, the following current upper limits must
not be exceeded:
Capacitor diameter
64,3 mm
40 A
76,9 mm
50 A
91,0 mm
70 A
I~
max
151
10/02
B43560 / B43580
Compact
–
105 °C
Dimensional drawings
Type B43560
Ring clip/clamp mounting
Type B43580
Threaded stud mounting
M5: min. reach of screw = 8 mm
M6: min. reach of screw = 12 mm*)
*) 8 mm for low-inductance design
Positive pole marking: +
The base of all types with threaded stud and
d
= 91 mm is fully insulated (the lengths
l
and
l
1
are
increased by 0,5 mm in these cases). For types with threaded stud and
d
≤
76 mm the base is not
insulated. Also refer to the notes on mounting given on page 168.
Dimensions and weights
Ter-
minal
M5
M5
M5
M6
M6
M6
M6
M6
M6
M6
M6
M6
Dimensions (mm) with insulating sleeve
Approx.
wt. (g)
440
570
640
540
750
840
1000
1300
1200
1500
1700
1900
d
I
±
1
I
1
±
1
112,2
137,2
149,7
111,5
136,5
149,0
174,5
226,5
149,8
175,3
196,3
226,3
I
2
17
17
17
17
17
17
17
17
17
17
17
17
+0
–1
l
3
7,0
+ 0,2/– 1
7,0
+ 0,2/– 1
7,0
+ 0,2/– 1
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
6,4
+ 1,1/– 0,8
d
1
M 12
M 12
M 12
M 12
M 12
M 12
M 12
M 12
M 12
M 12
M 12
M 12
d
2
max
d
3
max
a
8,2
8,2
8,2
17,7
17,7
17,7
17,7
17,7
17,7
17,7
17,7
17,7
13,5
13,5
13,5
17,7
17,7
17,7
17,7
17,7
17,7
17,7
17,7
17,7
+ 0,2
– 0,4
64,3
+ 0/– 0,8
105,7
64,3
+ 0/– 0,8
130,7
64,3
+ 0/– 0,8
143,2
76,9
+ 0/– 0,7
76,9
+ 0/– 0,7
76,9
+ 0/– 0,7
76,9
+ 0/– 0,7
76,9
+ 0/– 0,7
91,0
+ 0/– 2
91,0
+ 0/– 2
91,0
+ 0/– 2
91,0
+ 0/– 2
105,7
130,7
143,2
168,7
220,7
144,5
170,0
191,0
221,0
28,5
28,5
28,5
31,7
31,7
31,7
31,7
31,7
31,7
31,7
31,7
31,7
Dimensions are also valid for 2-pad solution and low-inductance design.
Packing
(For ecological reasons the packing is pure cardboard.)
Capacitor diameter
d
64,3 mm
76,9 mm
91,0 mm
Packing units (pieces)
15
12
8
152
10/02
B43560 / B43580
Compact
–
105 °C
Special designs
I
Low-inductance design
I
2-pad solution
Design for optimized connection of the capacitor to the heatsink when using base cooling.
This version is available for capacitors without threaded stud and for diameters
≥64,3
mm
(cf.
I~
R
(B) in table “Technical data and ordering codes” and useful life graphs).
Thermopad
thickness
0,5 mm
0,2 mm
Heatsink
KAL0823-3-E
Ordering codes:
Design
Low inductance (13 nH)
2-pad solution
Identification in 3rd
block of ordering code
M003
M006
Remark
For capacitors with diameter
d
≥
64,3 mm
For capacitors with diameter
d
≥
64,3 mm and
without threaded stud
Accessories
The following items are included in the delivery package, but are not fastened to the capacitors:
Thread
For terminals
M5
M6
For mounting M 12
Toothed
washers
A 5,1 DIN 6797
A 6,4 DIN 6797
Screws/Nuts
Cylinder-head screw M 5
×
8 DIN 84-4.8
Cylinder-head screw M 6
×
12 DIN 85-4.8
Maximum
torque
2
10
Nm
Nm
2,5 Nm
J 12,5 DIN 6797 Hex nut BM 12 DIN 439
The following must be ordered separately:
Ring clips
Clamps for capacitors with
d
≥
64,3 mm
Insulating parts
153
10/02
B 44 030 (cf. page 169)
B 44 030 (cf. page 173)
B 44 020 (cf. page 166)
B43560 / B43580
Compact
–
105 °C
Overview of available types
U
R
(VDC)
C
R
(µF)
2 200
2 700
3 300
3 900
4 700
6 000
6 800
8 200
10 000
12 000
15 000
350
Case dimensions
d
×
l
(mm)
400
64,3
×
105,7
450
64,3
×
130,7
76,9
×
130,7
76,9
×
168,7
91,0
×
144,5
76,9
×
220,7
91,0
×
191,0
91,0
×
221,0
64,3
×
105,7
64,3
×
130,7
76,9
×
105,7
64,3
×
143,2
76,9
×
105,7
76,9
×
130,7
76,9
×
143,2
91,0
×
144,5
76,9
×
220,7
91,0
×
221,0
91,0
×
221,0
91,0
×
144,5
91,0
×
170,0
76,9
×
220,7
76,9
×
130,7
The capacitance and voltage ratings listed above are available in different cases upon request.
Other voltage and capacitance ratings are also available upon request.
154
10/02
