5962H1024202KXA datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> 5962H1024202KXA

5962H1024202KXA: DescriptionComparator, 4 Func, 2000uV Offset-Max, 10000ns Response Time, CMOS, CDSO16, 0.300 X 0.400 INCH, 0.120 INCH HEIGHT, HERMETIC SEALED, CERAMIC, SOIC-16; CategoryAnalog mixed-signal IC Amplifier circuit; File Size252KB，5 Pages; ManufacturerCobham Semiconductor Solutions

Download Datasheet Parametric View All

5962H1024202KXA Overview

Comparator, 4 Func, 2000uV Offset-Max, 10000ns Response Time, CMOS, CDSO16, 0.300 X 0.400 INCH, 0.120 INCH HEIGHT, HERMETIC SEALED, CERAMIC, SOIC-16

5962H1024202KXA Parametric

Parameter Name	Attribute value
Maker	Cobham Semiconductor Solutions
Parts packaging code	SOIC
package instruction	SOP,
Contacts	16
Reach Compliance Code	unknown
ECCN code	3A001.A.1.A
Amplifier type	COMPARATOR
Maximum average bias current (IIB)	0.000002 µA
Maximum input offset voltage	2000 µV
JESD-30 code	R-CDSO-G16
Number of functions	4
Number of terminals	16
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	Not Qualified
Nominal response time	10000 ns
Maximum seat height	3.3528 mm
Supply voltage upper limit	6 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
total dose	300k Rad(Si) V
Base Number Matches	1

Preview

Download Datasheet

View All

Standard Products

Preliminary

RadHard-by-Design

RHD5911 Quad Comparator

Clocked

www.aeroflex.com/RHDseries

March 2, 2012

FEATURES

❑

Single power supply operation at 3.3V or 5.0V

Radiation performance

- Total dose:

>1Mrad(Si); Dose rate = 50 - 300 rads(Si)/s

- ELDRS Immune

- SEL Immune

>100 MeV-cm

/mg

- Neutron Displacement Damage >10

neutrons/cm

Ultra low power

Short Circuit Tolerant

Full military temperature range

Designed for aerospace and high reliability space applications

Packaging – Hermetic ceramic SOIC

- 16-pin, .411"L x .293"W x .090"Ht

- Weight - 0.8 grams max

Aeroflex Plainview’s Radiation Hardness Assurance Plan is DLA Certified to MIL-PRF-38534, Appendix G.

❑

GENERAL DESCRIPTION

Aeroflex’s RHD5911 is a radiation hardened, single supply, quad clocked comparator in a 16-pin SOIC

package. The RHD5911 design uses specific circuit topology and layout methods to mitigate total ionizing

dose effects and single event latchup. These characteristics make the RHD5911 especially suited for the

harsh environment encountered in Deep Space missions. It is guaranteed operational from -55°C to

+125°C. Available screened in accordance with MIL-PRF-38534 Class K, the RHD5911 is ideal for

demanding military and space applications.

ORGANIZATION AND APPLICATION

The RHD5911 quad clocked comparator is intended for operation with dynamic signals on either or both

inputs. Comparison is ’clocked’, that is the circuit functions as a regenerative clocked latch with a digital

output. For slow input signals with small input differences the comparators can be expected to respond to

small noise signals at the inputs. Feedback hysteresis is the responsibility of the user to avoid ’chattering’

on system noise.

The comparators will accept signals from (GND + 0.8V) to V

. The max clocked frequency is 50MHz.

The max clock-to-output delay is 10ns.

CMOS device drives have a negative temperature coefficient and the devices are therefore inherently

tolerant to momentary shorts, although on chip thermal shutdown is not provided. All inputs and outputs are

diode protected.

The devices will not latch with SEU events above 100 Mev-cm

/mg. Total dose degradation is minimal to

above 1Mrad(Si). Displacement damage environments to neutron fluence equivalents in the mid 10

neutrons per cm

range are readily tolerated. There is no sensitivity to low-dose rate (ELDRS) effects. SEU

effects are application dependant.

The RHD5911 16-pin clocked comparator allow pairs of comparators to access and hold data until needed.

SCD5911 Rev C
