www.bitechnologies.com
High Power Shielded Low Profile Surface Mount Inductors
Electrical / Environmental
•
•
Operating Temperature Range
Temperature Rise, Maximum
-40°C to +180°C
50°C
HM70
Specifications
Inductance
100kHz
0.1V
@ 0 Adc
@ I
rated
(µH±20%)
(µH)
Typ.
Min.
Typ.
1.00
0.63
0.70
1.33
0.93
1.16
1.94
1.28
1.60
0.83
0.488
0.61
1.50
0.80
1.00
2.10
1.12
1.40
1.25
0.92
1.02
1.68
1.15
1.44
0.70
0.40
0.52
1.20
0.80
0.90
DCR
(mΩ)
Typ.
2.53
3.38
4.71
1.75
2.16
3.48
1.75
2.13
1.05
1.68
(1)
Part
Number
HM70-101R0
HM70-201R3
HM70-201R9
HM70-25R80
HM70-301R5
HM70-302R0
HM70-401R2
HM70-401R6
HM70-50R70
HM70-501R2
I
rated
@ 25°C
(Adc)
16
16
12
18
16
12
34
20
30
24
(2)
Max.
2.90
3.74
5.42
2.01
2.48
4.00
1.80
2.36
1.26
2.00
Heating
Current
(Adc)
@∆50°C
15
13
11
19
17
14
22
20
31
25
(3)
Core Loss
Factor
K1
9.07E-11
1.24E-10
1.24E-10
1.29E-10
1.33E-10
1.33E-10
2.12E-10
2.12E-10
2.85E-10
2.85E-10
(4)
K2
86.721
79.134
95.591
68.630
97.919
113.246
72.072
76.245
42.602
53.556
Fig.
1
1
1
1
1
1
2
2
2
2
Notes:
(1) DC Resistance measured at 25°C
(2) The rated current (I
rated
) is the current at which the inductance will be decreased by 20% from its initial (zero DC) value.
(3) The heating current is the DC current, which causes the component temperature to increase by approximately 50°C. This current is determined by
soldering the component on a typical application PCB, and then apply the current to the device for 30 minutes.
(4) Core Loss approximation is based on published core data:
1.338
2.2546
Core Loss (Pfe) = K1 * (f)
* (K2∆I)
Where:
core loss = in watt
f = frequency in kHz
K1 and K2 = core loss factor
∆I
= delta I across the component in Amp.
K2∆I = one half of the peak to peak flux density across the component in Gauss
Outline Dimensions (mm)
Packaging
Standard:
Embossed Tape & Reel
Reel:
Diameter
Capacity Case Size 10,20,25,30
Case Size 40,50
=
=
=
13” (330.2mm)
500 Units
400 Units
Ordering Information
Model Series
HM70
50
1R2
Case Size
Inductance Code:
First 2 digits are significant. Last digit denotes the number of trailing zeros.
For values below 10µH, “R” denotes the decimal point.
2004 EDITION / MAGNETIC COMPONENTS SELECTOR GUIDE
We reserve the right to change specifications without prior notice.
27
