74F655A datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > accessories> 74F655A

Preview

74F655A: DescriptionOctal buffer/driver with parity, non-inverting 3-State; Categoryaccessories; File Size111KB，12 Pages; ManufacturerPhilips Semiconductors (NXP Semiconductors N.V.); Websitehttps://www.nxp.com/

Download Datasheet Compare View All

74F655A Overview

Octal buffer/driver with parity, non-inverting 3-State

Preview

Download Datasheet

View All

INTEGRATED CIRCUITS

74F655A*

Octal buffer/driver with parity, inverting

(3-State)

74F656A

Octal buffer/driver with parity,

non-inverting (3-State)

* Discontinued part. Please see the Discontinued Product List.

Product specification

IC15 Data Handbook

1991 Jul 17

Philips

Semiconductors

74F655A Related Products

	74F655A	74F656A	N74F656AN	N74F656AD	I74F656AD	I74F656AN
Description	Octal buffer/driver with parity, non-inverting 3-State	Octal buffer/driver with parity, non-inverting 3-State	Octal buffer/driver with parity, non-inverting 3-State	Octal buffer/driver with parity, non-inverting 3-State	Octal buffer/driver with parity, non-inverting 3-State	Octal buffer/driver with parity, non-inverting 3-State
Is it Rohs certified?	-	-	conform to	conform to	conform to	conform to
Maker	-	-	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)
package instruction	-	-	DIP, DIP24,.3	SOP, SOP24,.4	SOP, SOP24,.4	DIP, DIP24,.3
Reach Compliance Code	-	-	unknow	unknow	unknow	unknow
Control type	-	-	ENABLE LOW	ENABLE LOW	ENABLE LOW	ENABLE LOW
JESD-30 code	-	-	R-PDIP-T24	R-PDSO-G24	R-PDSO-G24	R-PDIP-T24
Logic integrated circuit type	-	-	BUS DRIVER	BUS DRIVER	BUS DRIVER	BUS DRIVER
MaximumI(ol)	-	-	0.064 A	0.064 A	0.064 A	0.064 A
Number of digits	-	-	8	8	8	8
Number of functions	-	-	1	1	1	1
Number of terminals	-	-	24	24	24	24
Maximum operating temperature	-	-	70 °C	70 °C	85 °C	85 °C
Output characteristics	-	-	3-STATE	3-STATE	3-STATE	3-STATE
Output polarity	-	-	TRUE	TRUE	TRUE	TRUE
Package body material	-	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	-	-	DIP	SOP	SOP	DIP
Encapsulate equivalent code	-	-	DIP24,.3	SOP24,.4	SOP24,.4	DIP24,.3
Package shape	-	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	-	-	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	IN-LINE
power supply	-	-	5 V	5 V	5 V	5 V
Maximum supply current (ICC)	-	-	110 mA	110 mA	110 mA	110 mA
Prop。Delay @ Nom-Su	-	-	16.5 ns	16.5 ns	18 ns	18 ns
Certification status	-	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Nominal supply voltage (Vsup)	-	-	5 V	5 V	5 V	5 V
surface mount	-	-	NO	YES	YES	NO
technology	-	-	TTL	TTL	TTL	TTL
Temperature level	-	-	COMMERCIAL	COMMERCIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	-	-	THROUGH-HOLE	GULL WING	GULL WING	THROUGH-HOLE
Terminal pitch	-	-	2.54 mm	1.27 mm	1.27 mm	2.54 mm
Terminal location	-	-	DUAL	DUAL	DUAL	DUAL
