BT137X-800

4Q Triac

9 October 2013

Product data sheet

1. General description

Planar passivated four quadrant triac in a SOT186A "full pack" plastic package intended

for use in general purpose bidirectional switching and phase control applications.

2. Features and benefits

•

High blocking voltage capability

Isolated package

Less sensitive gate for improved noise immunity

Planar passivated for voltage ruggedness and reliability

Triggering in all four quadrants

3. Applications

•

General purpose motor control

General purpose switching

4. Quick reference data

Table 1.

Symbol

DRM

TSM

T(RMS)

Quick reference data

Parameter

repetitive peak off-

state voltage

non-repetitive peak on- full sine wave; T

j(init)

= 25 °C;

state current

= 20 ms;

Fig. 4; Fig. 5

RMS on-state current

full sine wave; T

≤ 73 °C;

Fig. 1; Fig. 2;

Fig. 3

Static characteristics

gate trigger current

= 12 V; I

= 0.1 A; T2+ G+;

= 25 °C;

Fig. 7

= 12 V; I

= 0.1 A; T2+ G-;

= 25 °C;

Fig. 7

= 12 V; I

= 0.1 A; T2- G-;

= 25 °C;

Fig. 7

= 12 V; I

= 0.1 A; T2- G+;

= 25 °C;

Fig. 7

Conditions

Min

Typ

Max

800

Unit
