TP9383
NPN RF POWER TRANSISTOR
DESCRIPTION:
The
ASI TP9383
is a Common
Emitter Device Designed for FM
Broadcast Transmitter Applications in
the 88 to 108 MHz Band.
FEATURES INCLUDE:
•
High Efficiency
•
Gold Metallization
•
Emitter Ballasting
PACKAGE STYLE 500 4L FLG
MAXIMUM RATINGS
I
C
V
CBO
P
DISS
T
J
T
STG
θ
JC
16 A
60 V
230 W @ T
C
= 25
O
C
-55
O
C to+200
O
C
-55
O
C to+200
O
C
0.75
O
C/W
T
C
= 25
O
C
1 = COLLECTOR
2 = BASE
3 & 4 = EMITTER
CHARACTERISTICS
SYMBOL
BV
CBO
BV
CER
BV
CEO
BV
EBO
h
FE
C
OB
P
G
η
C
TEST CONDITIONS
I
C
= 100 mA
I
C
= 5.0 mA
I
C
= 100 mA
I
E
= 20 mA
V
CE
= 5.0 V
V
CB
= 28 V
V
CE
= 28V
P
OUT
= 150 W
I
C
= 1.0 A
f = 1.0 MHz
f = 108 MHz
R
BE
= 10
Ω
MINIMUM TYPICAL MAXIMUM UNITS
60
55
25
4.0
20
150
150
9.2
70
10.0
V
V
V
V
---
pF
dB
%
A D V A N C E D S E M I C O N D U C T O R, I N C.
7525 ETHEL AVENUE
•
NORTH HOLLYWOOD, CA 91605
•
(818) 982-1200
•
FAX (818) 765-3004
Specifications are subject to change without notice.
REV. A
1/1
