74HC/HCT643
Octal bus transceiver; 3-state;
true/inverting
Product specification
File under Integrated Circuits, IC06
December 1990
Philips Semiconductors
Product specification
Octal bus transceiver; 3-state;
true/inverting
FEATURES
•
Octal bidirectional bus interface
•
True and inverting 3-state outputs
•
Output capability: bus driver
•
I
CC
category: MSI
GENERAL DESCRIPTION
74HC/HCT643
The 74HC/HCT643 are high-speed Si-gate CMOS devices
and are pin compatible with low power Schottky TTL
(LSTTL). They are specified in compliance with JEDEC
standard no. 7A.
The 74HC/HCT643 are octal transceivers featuring true
and inverting 3-state bus compatible outputs in both send
and receive directions.
The “643” features an output enable (OE) input for easy
cascading and a send/receive (DIR) for direction control.
OE controls the outputs so that the buses are effectively
isolated.
QUICK REFERENCE DATA
GND = 0 V; T
amb
= 25
°C;
t
r
= t
f
= 6 ns
TYPICAL
SYMBOL
t
PHL
/
tPLH
PARAMETER
propagation delay
A
n
to B
n
; inverting
B
n
to A
n
; true
input capacitance
input/output capacitance
power dissipation capacitance per transceiver notes 1 and 2
CONDITIONS
HC
C
L
= 15 pF; V
CC
= 5 V
7
8
3.5
10
42
8
11
3.5
10
44
ns
ns
pF
pF
pF
HCT
UNIT
C
I
C
I/O
C
PD
Notes
1. C
PD
is used to determine the dynamic power dissipation (P
D
in
µW):
P
D
= C
PD
×
V
CC2
×
f
i
+
∑
(C
L
×
V
CC2
×
f
o
) where:
f
i
= input frequency in MHz
f
o
= output frequency in MHz
∑
(C
L
×
V
CC2
×
f
o
) = sum of outputs
C
L
= output load capacitance in pF
V
CC
= supply voltage in V
2. For HC the condition is V
I
= GND to V
CC
For HCT the condition is V
I
= GND to V
CC
−1.5
V
ORDERING INFORMATION
See
“74HC/HCT/HCU/HCMOS Logic Package Information”.
December 1990
2
Philips Semiconductors
Product specification
Octal bus transceiver; 3-state;
true/inverting
PIN DESCRIPTION
PIN NO.
1
2, 3, 4, 5, 6, 7, 8, 9
10
19
20
SYMBOL NAME AND FUNCTION
DIR
A
0
to A
7
GND
OE
V
CC
direction control
data inputs/outputs
ground (0 V)
data inputs/outputs
output enable input (active LOW)
positive supply voltage
74HC/HCT643
18, 17, 16, 15, 14, 13, 12, 11 B
0
to B
7
Fig.1 Pin configuration.
Fig.2 Logic symbol.
FUNCTION TABLE
INPUTS
OE
L
L
H
Notes
1. H
L
X
Z
= HIGH voltage level
= LOW voltage level
= don’t care
= high impedance OFF-state
DIR
L
H
X
INPUTS/OUTPUTS
A
n
A=B
inputs
Z
B
n
inputs
B=A
Z
Fig.3 IEC logic symbol.
Fig.4 Functional diagram.
December 1990
3
Philips Semiconductors
Product specification
Octal bus transceiver; 3-state;
true/inverting
DC CHARACTERISTICS FOR 74HC
For the DC characteristics see
“74HC/HCT/HCU/HCMOS Logic Family Specifications”.
Output capability: bus driver
I
CC
category: MSI
AC CHARACTERISTICS FOR 74HC
GND = 0 V; t
r
= t
f
= 6 ns; C
L
= 50 pF
T
amb
(°C)
74HC
SYMBOL
PARAMETER
+25
−40
to +85
−40
to +125
max.
135
27
23
135
27
23
225
45
38
225
45
38
90
18
15
ns
74HC/HCT643
TEST CONDITIONS
UNIT V
CC
WAVEFORMS
(V)
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
2.0
4.5
6.0
Fig.5
min. typ. max. min. max. min.
t
PHL
/ t
PLH
propagation delay
A
n
to B
n
;
inverting
propagation delay
B
n
to A
n
;
non-inverting (true)
3-state output enable time
OE, DIR to A
n
;
OE, DIR to B
n
3-state output disable time
OE, DIR to A
n
;
OE, DIR to B
n
output transition time
25
9
7
28
10
8
39
14
11
44
16
13
14
5
4
90
18
15
90
18
15
150
30
26
150
30
26
60
12
10
115
23
20
115
23
20
190
38
33
190
38
33
75
15
13
t
PHL
/ t
PLH
ns
Fig.6
t
PZH
/ t
PZL
ns
Fig.7
t
PHZ
/ t
PLZ
ns
Fig.7
t
THL
/ t
TLH
ns
Fig.5 and Fig.6
December 1990
4
Philips Semiconductors
Product specification
Octal bus transceiver; 3-state;
true/inverting
DC CHARACTERISTICS FOR 74HCT
For the DC characteristics see
“74HC/HCT/HCU/HCMOS Logic Family Specifications”.
Output capability: bus driver
I
CC
category: MSI
Note to HCT types
74HC/HCT643
The value of additional quiescent supply current (∆I
CC
) for a unit load of 1 is given in the family specifications.
To determine
∆I
CC
per input, multiply this value by the unit load coefficient shown in the table below.
INPUT
A
n
B
n
OE
DIR
UNIT LOAD COEFFICIENT
1.50
0.40
1.50
0.90
AC CHARACTERISTICS FOR 74HCT
GND = 0 V; t
r
= t
f
= 6 ns; C
L
= 50 pF
T
amb
(°C)
74HCT
SYMBOL
PARAMETER
+25
−40
to +85
−40
to +125
max.
30
ns
4.5
Fig.5
UNIT V
CC
WAVEFORMS
(V)
TEST CONDITIONS
min. typ. max. min. max. min.
t
PHL
/ t
PLH
propagation delay
A
n
to B
n
;
inverting
propagation delay
B
n
to A
n
;
non-inverting (true)
3-state output enable time
OE, DIR to A
n
;
OE, DIR to B
n
3-state output disable time
OE, DIR to A
n
;
OE, DIR to B
n
output transition time
10
20
25
t
PHL
/ t
PLH
13
23
29
35
ns
4.5
Fig.6
t
PZH
/ t
PZL
16
30
38
45
ns
4.5
Fig.7
t
PHZ
/ t
PLZ
17
30
38
45
ns
4.5
Fig.7
t
THL
/ t
TLH
5
12
15
18
ns
4.5
Fig.5 and Fig.6
December 1990
5
