JANTXV1N5194UR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> JANTXV1N5194UR

JANTXV1N5194UR: DescriptionRectifier Diode, 1 Element, 0.2A, Silicon, DO-213AA, GLASS PACKAGE-2; CategoryDiscrete semiconductor diode; File Size33KB，2 Pages; ManufacturerCompensated Devices Inc.

Download Datasheet Parametric View All

JANTXV1N5194UR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JANTXV1N5194UR	-	-	View	Buy Now

JANTXV1N5194UR Overview

Rectifier Diode, 1 Element, 0.2A, Silicon, DO-213AA, GLASS PACKAGE-2

JANTXV1N5194UR Parametric

Parameter Name	Attribute value
Maker	Compensated Devices Inc.
package instruction	GLASS PACKAGE-2
Reach Compliance Code	unknown
Is Samacsys	N
Other features	METALLURGICALLY BONDED
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	DO-213AA
JESD-30 code	O-LELF-R2
Number of components	1
Number of terminals	2
Maximum output current	0.2 A
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Certification status	Not Qualified
Guideline	MIL-19500/118F
surface mount	YES
Terminal form	WRAP AROUND
Terminal location	END
Base Number Matches	1

Preview

Download Datasheet

View All

• AVAILABLE IN

JAN, JANTX

AND

JANTXV

PER MIL-PRF-19500/118

• GENERAL PURPOSE SILICON DIODES

• METALLURGICALLY BONDED

1N5194UR

1N5195UR

1N5196UR

CDLL5194

CDLL5195

CDLL5196

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +175°C

Operating Current: 200 mA

Derating: 1.2mA/°C from 25ºC to 150ºC

1.0mA/°C from 150ºC to 175ºC

Forward Current: 650mA

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified

VRM

TYPE

V(pk)

CDLL, 1N5194UR

CDLL, 1N5195UR

CDLL, 1N5196UR

180

250

V(pk)

180

225

200

VRWM

TA = +150

°C

I FSM

TP=1/120 S

TA=25ºC

DIM

MILLIMETERS

INCHES

MIN MAX MIN MAX

1.60

1.70 0.063 0.067

0.41

0.55 0.016 0.022

3.30

3.70 .130 .146

2.54 REF.

.100 REF.

0.03 MIN.

.001 MIN.

FIGURE 1

DESIGN DATA

TYPE

@100mA

V dc

CDLL, 1N5194UR

CDLL, 1N5195UR

CDLL, 1N5196UR

0.8 - 1.0

IR1 at VRWM

IR2 at VRM

TA=25ºC

IR3 at VRWM

TA = 150

°C

CASE:

DO-213AA, Hermetically sealed

glass case. (MELF, SOD-80, LL34)

LEAD FINISH:

Tin / Lead

THERMAL RESISTANCE: (R

OJEC):

100 ˚C/W maximum

THERMAL IMPEDANCE: (Z

OJX): 70

˚C/W maximum

POLARITY:

Cathode end is banded.

MOUNTING POSITION:

Any.

MOUNTING SURFACE SELECTION:

The Axial Coefficient of Expansion

(COE) Of this Device is Approximately

+6PPM/°C. The COE of the Mounting

Surface System Should Be Selected To

Provide A Suitable Match With This

Device.

nA dc

100

A dc

22 COREY STREET, MELROSE, MASSACHUSETTS 02176

PHONE (781) 665-1071

FAX (781) 665-7379

WEBSITE: http://www.cdi-diodes.com

E-mail: mail@cdi-diodes.com
