S1003LS2 datasheet, PDF - EEWORLD Datasheet

S1003LS2: DescriptionSilicon Controlled Rectifier, 3A I(T)RMS, 3000mA I(T), 100V V(DRM), 100V V(RRM), 1 Element, TO-220AB; CategoryAnalog mixed-signal IC Trigger device; File Size1001KB，12 Pages; ManufacturerTeccor Electronics; Websitehttp://www.teccor.com/

Download Datasheet Parametric View All

S1003LS2 Overview

Silicon Controlled Rectifier, 3A I(T)RMS, 3000mA I(T), 100V V(DRM), 100V V(RRM), 1 Element, TO-220AB

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	FLANGE MOUNT, R-PSFM-T3
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Other features	SENSITIVE GATE
Shell connection	ISOLATED
Nominal circuit commutation break time	50 µs
Configuration	SINGLE
Critical rise rate of minimum off-state voltage	10 V/us
Maximum DC gate trigger current	0.2 mA
Maximum DC gate trigger voltage	0.8 V
Maximum holding current	6 mA
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
JESD-609 code	e0
Maximum leakage current	0.1 mA
On-state non-repetitive peak current	30 A
Number of components	1
Number of terminals	3
Maximum on-state current	3000 A
Maximum operating temperature	110 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Certification status	Not Qualified
Maximum rms on-state current	3 A
Maximum repetitive peak off-state leakage current	1 µA
Off-state repetitive peak voltage	100 V
Repeated peak reverse voltage	100 V
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Trigger device type	SCR
Base Number Matches	1
