H11G1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> H11G1

H11G1: DescriptionDarlington Output Optocoupler, 1-Element, 7500V Isolation; CategoryLED optoelectronic/LED photoelectric; File Size66KB，1 Pages; ManufacturerMotorola ( NXP ); Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

H11G1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	H11G1	-	-	View	Buy Now

H11G1 Overview

Darlington Output Optocoupler, 1-Element, 7500V Isolation

H11G1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Reach Compliance Code	unknown
Other features	UL RECOGNIZED
Coll-Emtr Bkdn Voltage-Min	100 V
Configuration	SINGLE
Current transmission ratio - minimum value	1000%
Nominal current transfer ratio	1000%
Maximum dark power	100 nA
Maximum forward current	0.06 A
Maximum forward voltage	1.5 V
Maximum insulation voltage	7500 V
JESD-609 code	e0
Installation features	THROUGH HOLE MOUNT
Number of components	1
Maximum on-state current	0.15 A
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
Optoelectronic device types	DARLINGTON OUTPUT OPTOCOUPLER
Maximum power dissipation	0.25 W
Maximum response time	0.000005 s
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Base Number Matches	1

Preview

Download Datasheet

View All

H11G1 Related Products

	H11G1	4N29A	4N32A	4N33	H11G2	0761605038_17	MOC8080
Description	Darlington Output Optocoupler, 1-Element, 7500V Isolation	Darlington Output Optocoupler, 1-Element, 7500V Isolation	Darlington Output Optocoupler, 1-Element, 1800V Isolation, DIP-6	Darlington Output Optocoupler, 1-Element, 7500V Isolation	Darlington Output Optocoupler, 1-Element, 7500V Isolation	Impact 100 Ohm 4 Pair Right Angle Daughtercard Receptacle, Right Guided	Darlington Output Optocoupler, 1-Element, 7500V Isolation, PLASTIC, DIP-6
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	-	incompatible
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	-	unknown
Other features	UL RECOGNIZED	UL RECOGNIZED	-	UL RECOGNIZED	UL RECOGNIZED	-	UL RECOGNIZED
Coll-Emtr Bkdn Voltage-Min	100 V	30 V	-	30 V	80 V	-	55 V
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	-	SINGLE
Current transmission ratio - minimum value	1000%	100%	500%	-	1000%	-	500%
Nominal current transfer ratio	1000%	100%	500%	500%	1000%	-	1117%
Maximum dark power	100 nA	100 nA	100 nA	100 nA	100 nA	-	100 nA
Maximum forward current	0.06 A	0.06 A	0.06 A	0.06 A	0.06 A	-	0.06 A
Maximum forward voltage	1.5 V	1.5 V	1.5 V	-	1.5 V	-	1.5 V
Maximum insulation voltage	7500 V	7500 V	1800 V	7500 V	7500 V	-	7500 V
JESD-609 code	e0	e0	e0	e0	e0	-	e0
Installation features	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT	-	THROUGH HOLE MOUNT	-	THROUGH HOLE MOUNT
Number of components	1	1	1	1	1	-	1
Maximum on-state current	0.15 A	0.15 A	0.15 A	-	0.15 A	-	0.15 A
Maximum operating temperature	100 °C	100 °C	100 °C	100 °C	100 °C	-	100 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-	-55 °C
Optoelectronic device types	DARLINGTON OUTPUT OPTOCOUPLER	DARLINGTON OUTPUT OPTOCOUPLER	DARLINGTON OUTPUT OPTOCOUPLER	DARLINGTON OUTPUT OPTOCOUPLER	DARLINGTON OUTPUT OPTOCOUPLER	-	DARLINGTON OUTPUT OPTOCOUPLER
Maximum power dissipation	0.25 W	0.25 W	0.25 W	-	0.25 W	-	0.25 W
Maximum response time	0.000005 s	0.000005 s	0.000005 s	-	0.0001 s	-	-
surface mount	NO	NO	NO	-	NO	-	NO
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)
Base Number Matches	1	1	1	1	1	-	1
